12v 15ah power tool battery

Specifications

12v 15ah power tool battery
Approved by UL and CE
With high performance
Long cylce life
Light weight



12v 15ah power tool battery





Advantage:



1) Safety: Currently the safest Li-ion battery, non-incinerated under over voltage of 10V charge, non-explosive under piercing.

2) Environmentally friendly. Non-toxic materials.

3)Powerful.

4)Long cycle life: 2000 cycles remain 80% capacity. Other Li-ion battery is only 300-500 cylces. Ni-Cd /Ni-MH and Lead battery is also only 300-500 cycles.



Stringently integrated with international management standard, our Batteries have secured CE, UL, SGS/RoHC, RBRC homologation and especially TS16949:2002 certificate issued by NQA for EV cars batteries design and manufacturing. Our batteries are well sold to Western Europe, North America, the Oceania, the Middle East, East Asia and Mainland China.





Specification:





Item		General Parameter
Model		IFR 32650
Casing material for single cell		steel case for single cells
Standard capacity(0.2C5A)		15Ah
Rated voltage		12V
Max.Charge voltage		14.6V
Cut-off voltage		10.0V
Standard charge and discharge current		0.2C5A
Charging Time		6.0hours
Max constant discharge current		2.5C5A
Weight(Approx)		About2kg
Impedance(Max, at 1000Hz.)		≤ 16mΩ
Charge method (CC/CV)	Standard	CC	0.2C		14.6V cut off
		CV	14.6V		0.05C cut off
	Rapid	CC	1C		14.6V cut off
		CV	14.6V		0.05C cut off
Operate temperature		Charge		0°C~45°C
		Discharge		-20°C~60°C
		Storage		-20°C~45°C





 The marks on package of the battery

• The warnings as following have to be indicated on the package of the battery
• Use the stated charger
• Don’t throw the battery into water and fire or don’t hot it up.
• Use the stated charger
• Don’t break up the battery



The marks on package of the battery



In order to prevent the battery leaking, getting hot and exploding, please pay attention to preventing measure as following:



(Warning!)



• Never throw the battery into water, keep it under dry, shady and cool circumstance when not use.
• Never keep the battery beside high temperature source examples: fire, heating machine and ect.
• Please use the stated charger when charging.
• Never upside down the positive and negative.
• Never cut the battery in socket directly
• Never throw the battery into fire or heating machine.
• Never connect the positive and negative of battery with metal.
• Never ship or store the battery together with metal
• Never knock, throw or trample the battery.
• Never cut through the battery with nail or other edge tool.



(Warning!)



• Never use or keep the battery under the high temperature. Otherwise it will cause battery heat, get into fire or lose some function and reduce the life.
• Never use the battery under strong static and strong magnetic field, otherwise it will destroy the protecting device
• If battery leaked, the electrolyte get into eyes, please don’t knead, please wash eyes by water and send to hospital. Otherwise it will hurt eyes
• If battery emit peculiar smell, heating, distortion or appear any unconventionality during using, storage or charging process, please take it out from device or charge and stop using.
• If the pole was duty, please clear it before using.
• Please encase the pole with isolative paper when you want to abandon the battery to prevent expolding and getting into fire.
