Pre-Stressed Corrugated Pipe Production Line (SJ75/30)

Specifications

Prestressed Corrugated Pipe Production Line
1.Total Power:45kw
2.Output:90-120kg/h
3.Main Material:PE
4.Extruder: SJ75/30

Pre-Stressed Corrugated Pipe Production Line (SJ75/30)







Product Description

(1)Commodity: Pre-stressed pipe production line
(Round and deplanate all-in-one machine)

(2) Components of Pre-stressed pipe production line:
1. SJ75/30 single-screw extruder 1set
2. ZK-120 Vacuum sizing cooling molding machine 1set
3. QL-160 traction cutting machine 1set
4. Stainless steel stacker(Length: 4000mm) 2sets
5. Specification of moulds and calibrating tool 11sets
(diameter[mm]: 50, 55, 60, 65, 70, 80, 90, 100, 110, 120, 130)

Auxiliary equipment:
1.200L mixer machine 1set
2. SWP360 crushers 1set

Total Installation power: 45-50kw
Actual use power: Less than 20kw
This pipe line could produce Pre-stressed corrugated pipe:
30mm-130mm (50; 55; 60; 65; 70; 80; 90; 100; 110; 120; 130)
Main material: PE
Max output: 120kg/h
Estimated actual traction speed: 0.5-2m/min

(3)Main technical parameters of Pre-stressed pipe production line:

Model SJ-75/30
L/D 30: 1
Pipe Diameter(mm) 30-130
Output(kg/h) 90-120
Production speed (m/min) 1.5-2.0
Power (kw) 45
The parameter may change without previous notice

(4)Product Application:
Slip casting duct assembly of Bridge,; Tunnel, Bridge, highway etc construction, cement structure etc.

(5)Advantage or summary:
Prestressed plastic corrugated pipe is not conductive to prevent stray current corrosion and metal is a good conductor of electricity;
Prestressed plastic corrugated pipe with better endurance performance, can greatly improve the fatigue resistance of the component
Specifications:
Model SJBG-130 SJBG160
Supporting host: SJ-75/30 single-screw extruder SJ-90/30 single-screw extruder
Mold size: φ 50-φ 130mm φ 110 ~ 160 mm
Module log: 42 42
Pipe status: Single-wall single-wall
Traction speed: 0.5-3.5M/min 0.3-3M/min
Cooling: Water cooling water cooling
Pipe cooling: Water cooling water cooling
