Dahua 4/6/8 Channel Mobile Dvr With Gps 3g Wifi

Specifications

1.4/6/8 cameras with SXGA realtime live view
2. H.264 dual stream
3.VGA/TV simultaneous video output
4. realtime playback

4/6/8 channel 2HDD MOBILE DVR

1. Up to 4/6/8 cameras with SXGA realtime live view

2. H.264 dual-stream video compression

3.DVR0404/0604MF-H: Full channel D1 realtime recording

4. DVR0804MF-U: 2CH@D1+6CH@CIF(1~25/30fps) realtime recording

5. VGA/TV simultaneous video output

6. Full channel synchronous realtime playback

7. Support 2 SATA HDDs, 1eSATA, 2 USB2.0

8. Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS

9. Aviation connectors adopted, Aluminum alloy case



Model		DVR0404MF-H	DVR0604MF-H	DVR0804MF-U
System
Main Processor		Embedded processor
Operating System		Embedded LINUX
Video
Input		4 channel	6 channel	8 channel
Standard		NTSC(525Line, 60f/s), PAL(625Line, 50f/s)
Audio
Input		4 channel	6 channel	8 channel
Output		1 channel
Two-way Talk		1 channel Input, 1 channel Output, BNC
Display
Interface		1 VGA, 1 TV
Resolution		1280x1024, 1024x768, 800x600
Display Split		1/4	1/4/8/9
Privacy Masking		4 rectangular zones (each camera)
OSD		Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Video/Audio Compression		H.264 / G711A
Resolution		D1( 704×576/704×480) /HD1(352x288/352x240)/ CIF ( 352×288/ 352×240 )/QCIF ( 176×144/176×120)
Record Rate	Main Stream	Full channel@D1(1~25/30fps)		2CH@D1+6CH@CIF (1~25/30fps)
	Sub Stream	CIF/QCIF(1~25/30fps)
Bit Rate		48~4096Kb/s
Record Mode		Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval		1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Trigger Events		Recording, PTZ, Tour, Alarm, Email, FTP, Buzzer & Screen tips
Video Detection		Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input		7 channel
Relay Output		2 channel
Playback & Backup
Sync Playback		1/2/4	1/2/4/9
Search Mode		Time/Date, Alarm, Motion Detection & Exact search (accurate to second)
Playback Functions		Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode		USB Device / eSATA Device / Network
Network
Ethernet		RJ-45 port (10/100M)
Wireless Network		Built-in 3G module(optional)
GPS		Built-in high accurate GPS module(optional)
Network Functions		HTTP, IPv4, TCP/IP, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, FTP, IP Filter
Max. User Access		10 users
Storage
Internal HDD		2 SATA ports
External HDD		1 eSATA port
Auxiliary Interface
USB		2 ports (1 Rear), USB2.0
RS232		1 port, For PC communication & Keyboard
RS485		1 port, For PTZ control
General
Power Supply		DC 8V~36V
Power Consumption		≤15W
Working Environment		-20°C~+60°C (Embedded Power-supply Included) / 5%~95%RH / 86~106kpa
Dimension (W×D×H)		202mm×252mm×91mm
Weight		3.5KG
Vibration-proof		5Hz~300Hz: X / Y / Z each direction 8 hours 5Hz~11Hz: Vibration amplitude 10mm 11Hz~300Hz: 50m/s2





Our main products :







CCTV :







1. Analogue cctv cameras,OEM standalone dvr,compression card ;dvr kits,PTZ cameras,



2. ip cameras(1080p/720p/960p) ,NVR



3. HD-SDI cameras,hd-sdi DVR,hd-sdi converters



4. Dahua products: Analogue dvr(Full D1/Half D1/Hybrid dvr/960h dvr/hd-sdi dvr)



                                  Dahua ip cameras,Dahua NVR,Dahua ptz cameras,Dahua compression cards.











Access control system



1. Biometric access control and time attendance



2. RFID access control system,keypad controller



3. Fingerprint Lock,Hotel lock,Electric lock,Magnetic lock







Alarm :



Burglar proof alarm system,PIR sensors,control panel(Honeywell,Paradox,Intelligence),Beam sensors,Fence beam sensors.Door contacts,accessories.
