Home > Products > Mechanical Splice > Telecommunication Equipment
Telecommunication Equipment
- 20 Piece / Pieces per Month
- Shanghai/Guangzhou
- T/T D/P D/A Credit Card
Product Details
| Place of Origin: | Shanghai, China | Brand Name: | Unikit | Model Number: | Telecommunication Equipment-fiber optic splice L925B |
Product Description
Specifications
1. Telecommunication Equipment2. ISO 9000:2008 , RoHs, TLC
Telecommunication Equipment
Operation Vedio:
/watch?v=orSerrrFt4U
/watch?v=EmUgU2Vaquc
Technical specification
Item | Parameter |
Applicable for | φ0.25 mm &φ0.90 mm fiber |
Size | 45*4.2*4.7mm |
Optical fiber diameter | 125μm ( 652 & 657 ) |
Tight buffer diameter | 250μm & 900μm |
Applicable mode | single & multimode |
Operation time | about 10s (without fiber cut) |
Insert loss | ≤ 0. 25 dB(1310nm & 1550nm) |
Return loss | ≤ -45dB |
Fastening strength of naked fiber | >5 N |
Clamping force of fiber with tight buffer | >8 N |
Using temperature | -40~+75°C |
Reusability (10 times) | IL ≤ 0.2dB RL ≤ 5dB |
