Zeolite Molecular Sieve Oxygen Generator for Hospital/Medical

Specifications

Oxygen Generator
1) Purity:90~98%
2) Flow:3~3000 Nm3/h
3) Pressure:0~0.5MPa
4)Power :380V/220V/50HZ

Oxygen Generator

Principles

N2 and O2 all have a quadrupole, for the reason that the quadrupole of N2 is bigger than the quadrupole of O2, the adsorption capacity by molecular sieve to N2 is stronger than O2.When the compressed air in certain pressure flow through adsorption bed formed by molecular sieve, the N2 gas is absorbed and O2 is obtained by separation.

The main part of O2 generator is two towers filled with molecular sieve ,when the compressed air get into adsorption tower, the N2 is absorbed by molecular sieve,O2 is produced from the export terminal .When one tower produces O2,another tower release the N2 by reducing the pressure to get the renewable desorption of carbon molecular sieve.Two towers alternate adsorption and regeneration to output O2 continuously.

Technical Features



1).Full Automation

All systems are designed for un-attended operation and automatic Oxygen demand adjustment.



2).Lower Space Requirement

The design and Instrument makes the plant size very compact,assembly on skids,prefabricated from factory.



3).Fast Start-up

Start-up time is only 5 minutes to get desired Oxygen purity.So these units can be switched ON&OFF as per Oxygen demand changes.



4).High Reliabiity

Very reliable for continuous and steady operation with constant Oxygen purity.Plant availability time is better than 99% always.



5).Molecular Sieves life

Expected Molecular sieves life is around 15-years i.e. whole life time of Oxygen plant.So no replacement costs.



6).Adjustable

By altering flow,you can deliver nitrogen with precisely the right purity.



Specifications&Selection



PSA Oxygen Generator
Capacity: 3~3000Nm3/h
Purity: 90-98%
Outlet pressure: 0.1-0.8Mpa



Model	Flow (Nm3/hr)	Air consumption (Nm3/min)	Inlet (mm)	Outlet (mm)
HL-WG-STDO-3	3	0.95	20	15
HL-WG-STDO-6	6	1.9	25	15
HL-WG-STDO-10	10	2.8	32	15
HL-WG-STDO-20	20	5.6	40	20
HL-WG-STDO-30	30	8.4	50	20
HL-WG-STDO-50	50	14	65	25
HL-WG-STDO-80	80	22	65	32
HL-WG-STDO-100	100	28	80	32
HL-WG-STDO-150	150	42	100	40
HL-WG-STDO-200	200	56	125	40



Paper and Pulp industries

Glass industries

Metallurgical industries

Chemical industries

Water and Wastewater treatment

Fish farming





Why choose us ?



 1.Convenient to install



 2.More economic than other oxygen supplying methods



 3.The macaronis design realizes the automatic running



 4.Peak value / the security system of the trouble



 5.The high-quality components and parts are the reliable assurance of steady operation



 6.Oxygen content shows in succession, equipping the transfinite automatic alarm system:



 7.The high-quality zeolite molecular sieve:



 8.The advanced loading technology guarantees the service life of equipments



 9.The automatic alarm system for sinking of the carbon molecule sieve:



 10.The unqualified oxygen automatic emptying system



 11.Differential pressure indication, concentrating blow down system:



 12.The unique inter-circle switching techniques’ of system
