Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Wire > Stainless Steel Wire Rope,1x7,, 7x7, 7x19..
US$ 0.31 - 22
MOQ: 300 Meters
Key Specifications
Get Latest Price
Steel Grade:
Stainless Steel,201,301,304,316...etc.
Standard:
AISI, ASTM, BS, DIN, GB, JIS
Wire Gauge:
customized
Payment & Shipping
Payment Methods:
Port of Shipment:
shangahi
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Steel Grade
Stainless Steel,201,301,304,316...etc.
Standard
AISI, ASTM, BS, DIN, GB, JIS
Wire Gauge
customized
Place of Origin
Jiangsu, China
Application
Other, Construction,Industry,machine, Aircraft,Rigging...
Model Number
all size,as requirements.
Brand Name
TELLO
Specifications
tello stainless steel wire rope 1*7,6*19,7*7..1.size: various(customized)
2.One-stop production line
Tello stainless steel wire rope 1*7,7*7...
| construction | dia(mm) | tolerance | Appro Weight(kg/100m) | MBL/KN |
| 1*7 | 0.3 | 0/+0.08 | 0.05 | 0.075 |
| 0.4 | 0.08 | 0.133 | ||
| 0.6 | 0.18 | 0.3 | ||
| 0.8 | 0.32 | 0.533 | ||
| 1 | 0.51 | 0.832 | ||
| 1.2 | 0.73 | 1.198 | ||
| 1.5 | 1.14 | 1.872 | ||
| 1.8 | 1.64 | 2.696 | ||
| 2 | 2.02 | 3.325 | ||
| 2.5 | 3.16 | 5.201 | ||
| 3 | 4.55 | 7.489 | ||
| 4 | 0/+0.07 | 8.08 | 13.314 | |
| 1*19 | 0.8 | 0/+0.08 | 0.31 | 0.53 |
| 1 | 0.49 | 0.82 | ||
| 1.5 | 1.11 | 1.85 | ||
| 1.8 | 1.6 | 2.67 | ||
| 2 | 1.98 | 3.3 | ||
| 2.5 | 3.09 | 5.16 | ||
| 3 | 4.45 | 7.43 | ||
| 4 | 0/+0.07 | 7.92 | 13.21 | |
| 5 | 12.37 | 20.64 | ||
| 6 | 0/+0.06 | 17.82 | 29.72 | |
| 8 | 0/+0.05 | 31.68 | 52.85 | |
| 10 | 49.6 | 82.58 | ||
| 12 | 71.28 | 118.91 | ||
| 1*37 | 5 | 0/+0.07 | 12.23 | 20.41 |
| 6 | 0/+0.06 | 17.6 | 29.39 | |
| 8 | 0/+0.05 | 31.3 | 52.25 | |
| 10 | 48.9 | 81.64 | ||
| 12 | 70.42 | 117.56 | ||
| 14 | 95.84 | 160.01 | ||
| 16 | 125.18 | 208.99 | ||
| 18 | 158.44 | 264.51 | ||
| 20 | 195.6 | 326.56 | ||
| 7*7 | 0.33 | 0.037 | 0.1 | |
| 0.36 | 0/+0.08 | 0.054 | 0.15 | |
| 0.5 | 0.09 | 0.14 | ||
| 0.8 | 0.25 | 0.29 | ||
| 1 | 0.39 | 0.56 | ||
| 1.2 | 0.56 | 0.81 | ||
| 1.5 | 0.88 | 1.27 | ||
| 1.8 | 1.27 | 1.83 | ||
| 2 | 1.57 | 2.25 | ||
| 2.5 | 2.45 | 3.52 | ||
| 3 | 3.53 | 5.07 | ||
| 4 | 0/+0.07 | 6.28 | 9.01 | |
| 5 | 9.82 | 14.09 | ||
| 6 | 0/+0.06 | 14.14 | 20.29 | |
| 8 | 0/+0.05 | 25.15 | 36.07 | |
| 10 | 39.3 | 56.36 | ||
| 12 | 56.59 | 81.16 | ||
| 7*19 | 1.2 | 0/+0.08 | 0.54 | 0.75 |
| 1.5 | 0.85 | 1.17 | ||
| 1.8 | 1.23 | 1.68 | ||
| 2 | 1.52 | 2.08 | ||
| 2.5 | 2.38 | 3.25 | ||
| 3 | 3.42 | 4.69 | ||
| 4 | 0/+0.07 | 6.09 | 8.33 | |
| 5 | 9.52 | 13.03 | ||
| 6 | 0/+0.06 | 13.71 | 18.76 | |
| 7 | 18.66 | 25.54 | ||
| 8 | 0/+0.05 | 24.38 | 33.35 | |
| 10 | 38.1 | 52.12 | ||
| 12 | 54.86 | 75.05 | ||
| 14 | 74.67 | 102.16 | ||
| 16 | 97.53 | 133.43 | ||
| 18 | 123.44 | 168.88 | ||
| 20 | 152.4 | 208.49 | ||
| 24 | 219.45 | 300.23 | ||
| 26 | 257.55 | 352.35 | ||
| 6*19S/W+IWRC | 8 | 0/+0.05 | 25.92 | 35.77 |
| 10 | 40.5 | 55.89 | ||
| 12 | 58.32 | 80.48 | ||
| 14 | 79.38 | 109.55 | ||
| 16 | 103.68 | 143.08 | ||
| 18 | 131.22 | 181.09 | ||
| 20 | 162 | 223.57 | ||
| 6*36S/W+IWRC | 8 | 0/+0.05 | 26.75 | 35.77 |
| 10 | 41.8 | 55.89 | ||
| 12 | 60.19 | 80.48 | ||
| 14 | 81.93 | 109.55 | ||
| 16 | 107.01 | 143.08 | ||
| 18 | 135.43 | — | ||
| 20 | 167.2 | — | ||
| 22 | 202.31 | — | ||
| 24 | 240.77 | — | ||
| 26 | 282.57 | — | ||
| 28 | 327.71 | — | ||
| 19*7 | 4 | 0/+0.07 | 6.43 | 7.61 |
| 5 | 10.05 | 13.58 | ||
| 6 | 0/+0.06 | 14.47 | 19.56 | |
| 7 | 19.69 | 26.62 | ||
| 8 | 0/+0.05 | 25.73 | 34.77 | |
| 10 | 40.2 | 54.32 | ||
| 12 | 57.89 | 78.22 | ||
| 14 | 78.79 | 106.47 | ||
| 16 | 102.91 | 139.06 | ||
| 18 | 130.25 | 176 | ||
| 20 | 160.8 | 217.29 |
selection Material: Stainless Steel,201,301,304,316...
Packing:wood reel,plastic reel , carton, as your requirements.
We are the professional manufactury for stainless steel products.
Various kinds of stainless steel products with high quality and the factory price.
