Mini bulldozer, mini skid loader with bulldozer for sale

FOB Price

Negotiable / Set

1 Set(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition:	New	Brand Name:	TAIAN	Model Number:	MS500
Place of Origin:	Shandong, China	Type:	Skid Steer Loader	Moving Type:	Wheel Loader
Dimension(Long * Breadth * High):	1780x1100x1300mm	Rated Load:	500kg	Certification:	CE&ISO
Warranty:	one year or 1000 work hours whichever comes first	After-sales Service Provided:	Engineers available to service machinery overseas

Mini bulldozer, mini skid loader with bulldozer for sale

Advantage

1.Compared with other similar size machine, our MS500 is super powerful with 500kg lifting capacity.

2.We adopted water cooled gasoline engine which has much better cooling efficient, and for such compact machine this is very significant.

3.The unique rotatable oil tank design makes the maintenance much more easier and touchable.

4.The self levering feature also makes it stand out from other mini skids.

5.Different type/brand engines, wheel/track type available, offer many choices to customers

Specifications

Model	MS500 mini bulldozer
Moving type	Crawler or Wheel
Max. Length (without bucket)	1760 mm
Max. width	1100 mm
Max. height	1295 mm
Speed	5km/h
Rated loading capacity	500kg (including attachment)
Tipping load	1040kg
Max. reach	1800mm
Pushing power	8.2KN
Weight (without attachment)	1050kg
Hydraulic oil flow	30L/min
Track oil flow	46L/min
Oil tank capacity	38L
Oil mode	L-HL46
Gasoline oil capacity	28L/min
Battery capacity	45Ah
Voltage	12v
Wheel size	6.50-10
Inflation pressure	790kpa
Engine	Kohler CH752, 23HP
Engine type	Gasoline, 2 cylinder, air cooled
Rotation speed	3600r/min
Optional Chinese Diesel Engine 1
Engine model	Changchai 3M78, 21.76HP
Engine type	Diesel, 3 cylinders, water cooled
Engine speed	3000r/min
Machine Size(LxWxH/mm) without bucket	1910mmx1150mmx1345mm
Weight (without attachment)	1240KG
Optional Imported Diesel Engine 2
Engine model	Yanmar 3TNV76
Engine Power	25HP
Rotation speed	2800r/min
Engine type	Diesel, 3 cylinders, water cooled

Our Services

1. Quick response to every inquiry.

2. Professtional and detailed answer to any of customer's questions.

3. Strict QC and in time delivery

4. Offer all relative material for customer to know and better use the machine.

5. Periodically after service follow up, offer any necessary support if needed.

Details

Packing & delivery

Demo sample 1 set by plywood box shipped by LCL.

Bulk purchase: 6sets/20'GP; 12sets/40'GP
