quality products digital generator with ats

Specifications

digital generator
air cooled Diesel engine
1 or 3 phase,brushless alternator
copper wire, made in china
ATS,Digital meters

quality products digital generator with ats



1) air-cooled ,Diesel type

2) Advanced generator and soundproof ,Silent /canop type
3) Single and three-phase engines are available

4) Electric start ,Low fuel comsuption

5) It is suitable for 50Hz and 60Hz. The dimensions is decided by the power

6) Speed: 3000rpm /3600rpm

7) ATS (automatic transfer switch)

8) digital meter



Accessories

1)Standard accessories:Standard 40 radiator mounted on skid,Common stell frame ,Circuit breaker ,damper ,exhaust silencer ,flexible pipe,battery and connecting wires ,standard tools kit ,operation manual and document

2)Optional accessories:Engine coolant and oil heater ,alternator space heater ,cooling for heat exchanger ,communication interface ,battery charger by main supply ,daily fuel tank ,ATS and paralleling system ,soundproof canopy and moving trailer .



Portable Diesel Generator Specification:

Air-cooled Diesel Generator Sets (Single Phase)
Model	SML3GF-LN		SML5GF-LN		SML6GF-LN
Rated frequency(Hz)	50	60	50	60	50	60
Rated voltage(v)	110,120,220,230,240,220/110,240/120
rated output power(kw)	2.8	3.3	4.2	5	5	5.5
Max output power(kw)	3	3.6	5	5.5	5.5	6
Dc output	12V-8.3A
Power factor cos1	1
Phase number	Single-phase
Fuel tank capacity (l)	16
Continuour running time (hr)(at rated power)	12.5	11.5	8.5	7.5	8.5	7.5
Noise level{db(A)/7m}(zero load-full load)	70-74
Overall dimension{mm}(LXWXH)	825*520*740		910*520*740		935*520*715
Packing dimension {mm}(lXWXH)	855*550*780		950*550*780		960*550*770
Net weight kg	132		156		171
Gross weight  kg	150		170		185
starter system	electric starter
Engine model	178FGE		186FGE		186FAGE
Engine type	Single cylinder,4-stroke,air-cooled,vertical,diesel engine
Bore*stroke(mm)	78*62		86*70		86*72
Displancement (cc)	296		406		418
Rated rotation speed (rpm)	3000	3600	3000	3600	3000	3600



Diesel Generator Package

Certificate:SONCAP,CE,COI,SGS,BV,EPA



Characteristics:

1. Powered by air-cooled 4-stroke diesel engine.

2. 12-volt DC auxiliary charging (car/boat battery).

3. Injection nozzle with electric control clique.

4. Low oil alert system shuts down the engine automatically.

5. Wheels for easy move.

6. Key operated ignition switch for the standard electric starter.

7. Standard equip with 24Ah dry battery.

8. Hydraulic-Magnetic circuit breaker.



Diesel Generator,Gasoline Pump,Water Pump,Protable Genset,Moving Trailer

Warranty policy

Guarantee for one year or 1200 hours whichever reach first from ex-factory date ,During the guarantee period ,Saint will provide the free easy-damageable spare parts of diesel engine caused by our quality of production or raw material,After expiration ,"Saint "provides cose spare pars maintenance of genset
