Home > Lights & Lighting > LED Interior Lighting > LED Down Light > 2015 Hot Seller Square LED Downlight 4 Heads

2015 Hot Seller Square LED Downlight 4 Heads

2015 Hot Seller Square LED Downlight 4 Heads photo-1
2015 Hot Seller Square LED Downlight 4 Heads photo-2
2015 Hot Seller Square LED Downlight 4 Heads photo-3
2015 Hot Seller Square LED Downlight 4 Heads photo-4
2015 Hot Seller Square LED Downlight 4 Heads photo-5
2015 Hot Seller Square LED Downlight 4 Heads photo-6
US$ 55 - 59 MOQ: 2 Pieces
Key Specifications
Get Latest Price
LED Light Source:
Cree COB
Warranty(Years):
3
Input Voltage(V):
AC100~240V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
LED Light Source Cree COB
Warranty(Years) 3
Input Voltage(V) AC100~240V
Lamp Power(W) 48
Lamp Luminous Flux(lm) 4080
Lamp Luminous Efficiency(lm/w) 85
Color Temperature(CCT) Other, Warm White Neutral White Cold White
Working Temperature(℃) -20, 50
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum Alloy
IP Rating IP33
Certification C-tick, CCC, CE, EMC, Energy Star, ETL, SAA, UL
Model Number OP-GDL01121-4C
Place of Origin Guangdong, China
Brand Name OPTE

   2015 Hot Seller Square LED Downlight 4 heads

Product Description



The Most Professional OEM/ODM Commercial LED Lighting Manufacturer



2015 Hot Seller Square LED Downlight 4 heads



2015 Hot Seller Square LED Downlight 4 heads



 2015 Hot Seller Square LED Downlight 4 heads



2015 Hot Seller Square LED Downlight 4 heads



2015 Hot Seller Square LED Downlight 4 heads



2015 Hot Seller Square LED Downlight 4 heads




  2015 Hot Seller Square LED Downlight 4 heads





Technical Parameters



Model No.

OP-GDL0112-4C

Related wattage:

48W

Input voltage:

100~240 VAC

Housing Color

White

Operating frequency:

50/60 Hz

Power factor

0.9

Beam angle

15° 24 °

LED brand

CREE COB

LED Qty

4 pcs

Luminous flux

4080 lm

Light color

warm white/ nature white/ cool white

CRI

≥85

Diameter / Cut-out

232*232*121mm  /220mm* 220mm

Driver

External

IP Rating

IP33

Dimmable

Optional

Main material

Aluminum alloy

Working temperature

-20~45 °C

Storage temperature

-20~80 °C

Lifespan

50000 h

Certificates & standard

CE, ROHS, FCC, SAA

Warranty

3 years



Other models you might interest



Model No.

Power

LED

Heads

Lumen

Beam Angle

Cut-out

Dimension

OP-GDL0108-1C

1*8W

Cree

1

680LM

15° 24°

100*100mm

Φ110*110*92mm

OP-GDL0108-2C

2*8W

Cree

2

1364LM

15° 24°

180*100mm

Φ190*110*92mm

OP-GDL0108-3C

3*8W

Cree

3

2040LM

15° 24°

255*100mm

Φ263*110*92mm

OP-GDL0108-4C

4*8W

Cree

4

2720LM

15° 24°

180*180mm

Φ190*190*92mm

OP-GDL0112-1C

1*12W

Cree

1

1020LM

15° 24°

120*120mm

Φ133*132*121mm

OP-GDL0112-2C

2*12W

Cree

2

2040LM

15° 24°

220*120mm

Φ232*132*121mm

OP-GDL0112-3C

3*12W

Cree

3

3060LM

15° 24°

330*120mm

Φ340*132*121mm

OP-GDL0112-4C

4*12W

Cree

4

4080LM

15° 24°

220*220mm

Φ232*232*121mm









Certifications

 2015 Hot Seller Square LED Downlight 4 heads2015 Hot Seller Square LED Downlight 4 heads



Company Information

2015 Hot Seller Square LED Downlight 4 heads

2015 Hot Seller Square LED Downlight 4 heads



Peoduct Application



2015 Hot Seller Square LED Downlight 4 heads



FAQ



Q1 How do you evaluate LED products?

Lumen output is only part of the story and can be misleading. To fully evaluate an LED product one needs to review the overall system efficiency,optical control, thermal management of the LEDs, and know at what point in time the fixture will reach 30 percent lumen depreciation. Products with good optical efficiency and thermal management will be able to deliver more lumens, on average, than traditional HID products.



Q2 How long will my LED Light last?

LEDS last up to 8 times longer than CFL and Incandescent lamps and you can expect at least 35,000 hours of use from your LED Lamp.



Q3 How should i choose the color temperature ?

3000K, warm and appealing, for leisure atmosphere and accent lighting

4000K, natural effect, ideal application on public places.

6000K, bright and efficient, for pleasant and healthy office environment.

LED Downlight  is popular for store,hotel,shopping malls,gellery, museum,office



Q4 Does OPTE have ability to do OEM products?

 In the past years OPTE has gained a lot of work on OEM of LED lighting and LED strip lighting. And thanks to these works, we gained a lot of valuable OEM experience. We will still strictly follow the principal that we won’t disclose or sell customer’s unique designs to any other third party.



Q5 How your company control the cost of the lights ?

We have a industrial chain which involve a completed system like Housing Die-Coasting , LED encapsulation and Driver R&D Departments , to make sure you our lights in competitive and high quality



Q6 What should i do if any lights not good in quality

Each lights under strictly quality inspection and 24 Hrs aging test before sending to you , we make sure the reject ratio under 3‰ , unfortunately , if any light failures in quality within warranty period , please offer the proof (Picture Video) to us ,we will replace & fix free of charge and bear the freight cost



Q7 Is there any cheap shipping cost to our country ?

 We have long term cooperation forwarder in DHL FedEx ,Air freight sad Sea freight, we will try our best to get the best freight rate for you
