Competitive Factory 1Ton and 3300mm Electric Reach Stacker Price

FOB Price

USD $6,900 - $7,200 / Piece

1 Piece(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Place of Origin	Jiangsu, China
Brand Name	Huize	Model Number	HZCQD1033-05
Type	Powered Pallet Truck	Power Souce	AC Motor
Rated Loading Capacity	1000kg	Max. Lifting Height	3300mm
Min. Lifting Height	30mm	Fork Length	1070mm
Fork Width	600mm	Certification	ISO9001,CE,BV
After-sales Service Provided	Engineers available to service machinery overseas

Competitive Factory 1Ton and 3300mm Electric Reach Stacker Price

we are 9 years experienced manufacturer

For Product Character

1.High tensile strength mast material ,High stability

2.VAT System, Diecast hydraulic pump unit

3.Low failure rate,Low noise, No pollution

4.Little turning radius,suitable for narrow aisle

5. High lifting height , suitable for stacker in high place

6. Firm and beautiful structure, Easy operation

7. Application: Stacker,short distance carry pallets and cargoes in the good yards

Certificate

ISO9001,CE,SGS

Min Order: 1 sets

Port: Shanghai, Ningbo, Qingdao

Payment: TT, LC

Delivery: 10-15 workingdays after received 30% deposit

Packing: STANDARD EXPORT PACKING

Feature

1.	Feature
1.1	Name	Electric Reach Stacker
1.2	Model	HZCQD1033-05
1.3	Mast	Double
1.4	Power	Battery
1.5	Manipulation	Standing Steer Type
1.6	Braking Mode	Electromagnetic braking
1.7	Load Capacity	1000kg
1.8	Load Center	550mm
1.9	Hydro cylinder	Double
1.10	Color	Red, Yellow ,Blue ,Gray
1.11	Surface Treatment	Baking Painted
2.	Wheel
2.1	Wheel Type	Polyurethane
2.2	Driving wheel No.& Size	1pcs, φ250mm*80mm
2.3	Balance wheel No.& Size	2 pcs, φ150mm*50mm
2.4	Load Wheel No. & Size	2 pcs, Φ178mm*80mm
3.	Size
3.1	Single Fork Size	1070mm100mm38mm
3.2	Fork Overall Width	200mm~600mm
3.3	Overall Length	3470mm
3.4	Overall Width	1000mm
3.5	Overall height	2250mm
3.6	Max Lifting Height	3300mm
3.7	Lowered Height	30mm
3.8	Reach Distance	500mm
3.9	Forward Max	3°
3.10	Backwards Max	5°
3.11	Aisle Width	1100mm
3.12	Min Aisle Width for Turning Around	4000mm
3.13	Turning Radius	3800mm
4.	Performance
4.1	Traveling Speed(with/without load)	4/6 km/h
4.2	Lifting Speed(with/without load)	60/65 mm/s
4.3	Lowering Speed(with/without load)	100/70 mm/s
4.4	Gradient(with/without load)	5/8 %
4.5	Braking Length(with/without load)	500/350 mm
5.	Driving
5.1	Driving Motor	1.2 KW
5.2	Lifting Motor	2.5 KW
5.3	Driving Control Type	Horizontal AC
6.	Battery
6.1	Battery Voltage/Capacity	24V210AH
6.2	Times of Recharged for Battery	750 Times
6.4	Charger	24V30A

Photos
