Fork Side Shift Reach Stacker For Double-faced Pallet
- 0 per Month
- shanghai
- T/T L/C D/P D/A PayPal
-
1.5T 1.6m passed CE AC battery powered standing new full electric reach stacker for sale
-
1.2T 4.5m passed CE AC battery powered standing new full electric reach stacker for sale
-
1T 2m passed CE AC battery powered standing new full electric reach stacker for sale
-
alibaba suppliers bear heater in electric heaters
-
tool heater,china manufacture bearing heater
-
cheap price supplier of induction bearing heater
Product Details
| Condition: | New | Place of Origin: | Jiangsu, China | Brand Name: | XIANGYUAN |
| Model Number: | HZCQD1033-05 | Certification: | CE,SGS,BV | Warranty: | 1 years |
| After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Fork Side Shift Reach Stacker For Double-faced Pallet
(electric walking ,electric lifting )
Fork Side Shift Reach Stacker For Double-faced Pallet
1.Our full electric stackers are suitable to carry and stack in narrow channel and limted room.For example, high rack warehouse,supermarket,workshop.
2.Our full electric stackers are controlled by computer program.
3.Masts of our full electric stackers are made of steel imported from German.
4.Battey of our full electric stackers can be fitted from three directions
5.We can customize according to clients requirements.
|
|
Characteristic | |||
1 | Name |
| Full electric reach stacker |
2 | Model |
| HZCQD1033-05 |
3 | Mast steps |
| double |
4 | Dynamic unit |
| battery |
5 | Operation mode |
| Standing |
6 | Load capacity | Q(Kg) | 1000 |
7 | Load center | C(mm) | 550 |
8 | hydraulic cylinder |
| Single cylinder |
9 | Color |
| Red, yellow, blue, gray |
10 | Surface treatment |
| Paint |
11 | Wheel |
Polyurethane | |
| 12 | G.W/N.W | kg | 1168/1165 |
Fork Side Shift Reach Stacker For Double-faced Pallet
size | |||
1 | Lifting height | h(mm) | 3000 |
2 | Fork minimum height | h(mm) | 30 |
3 | Overall height when fork up to maximum height | h(mm) | 3500 |
4 | Overall length | L(mm) | 3470 |
5 | Overall width | b(mm) | 1000 |
6 | Fork size | l/e/s(mm) | 1070*100*38 |
7 | Fork overall width | b(mm) | 200~600 |
8 | Overall height | h(mm) | 2250 |
9 | Reach distance | l(mm) | 500 |
10 | Rake angle | β | 3° |
11 | Inclined angle | α | 5° |
12 | Front wheel size | mm | φ178*80 |
13 | Driving wheel size | mm | φ250*80 |
14 | Balance wheel size | mm | φ150*50 |
15 | Channel width | Ast(mm) | 1100 |
16 | Minimum channel width truck turning around | Ast(mm) | 4000 |
17 | Turning radius | Wa(mm) | 3800 |
Fork Side Shift Reach Stacker For Double-faced Pallet
Driving | |||
1 | Driving wheel | Kw | 1.2 |
2 | Lifting motor | Kw | 2.5 |
3 | Battery | V/Ah | 24/210(1 group) |
4 | Battery recharge cycles |
| 750 |
5 | Battery weight | Kg | 187 |
6 | Charger |
| 24V30A |
7 | Driving Control Type |
| AC |
8 | Driving wheel type |
| Horizontal |
Fork Side Shift Reach Stacker For Double-faced Pallet
Packing and shipping | |||
1 | packing method |
| Packaging as a whole |
2 | packing |
| Angle iron + bubble wrap |
3 | packing size | L/B/H(m) | 3*1.2*2.4 |
5 | How many boxes does each product have |
| 2 |
6 | Number of 20-foot containers | set | 8 |
7 | Number of 40-foot containers | set | 16 |
3.3m pa
ssed CE AC battery powered standing new full electric reach stacker for sale
24 hours online service
Enquiry will be replied in 2 hours
One year warranty
1%-2%Spare Parts
CKD and SKD are available
Free parts for any breakdown with convincing evidence
Since 2006
Fork Side Shift Reach Stacker For Double-faced Pallet
Specializing in pallet truck,pallet stacker,all warehouse handling equipments.
Consecutive sales increasement of 5 years
Passed the ISO9001:2008 and international certificate as CE,BV,SGS
Provide OEM and ODM service to overseas customer
Export to more than 15 countries in Europe,the Middle East,Southeast Asia,Africa,South America and areas etc.
Q1:Can I have a sample for testing?
A: Actually we think samples are not very important.You can buy from anywhere.But we think
our cargos will better then any others.
Samples will be 10% higher then the cargo.
Fork Side Shift Reach Stacker For Double-faced Pallet
Q2:Can I add my logo on the kitchen appliances?
A:Yes,OEM and ODM are available for us.
But you should send us the Trademark authorization letter.
Q3:How can i get the after-service?
A:We will send you the spare parts by free if the problems caused by us.
If it is the men-made problems,we also send the spare parts,but you should pay.
For our range pallet truck it is lifelong maintenance.
Q4 :Do you have inspection procedures for your products?
A:100% self-inspection before packing
Q5:Can we mix the 20ft container?
A: Yes,if the items are meet our min order qty.
Q6:Can I have a visit to your factory before the order?
A: Sure,welcome to visit our factory.
Here is our factory address:Taizhou city,Jiangsu,China.
Our factory is near Shanghai Airport.We can pick you up in the airport.
Hotel booking service is available .
1
T 3.3m passed CE AC battery powered standing new full electric reach stacker for sale
