4 in 1 out 4-way perallel solar branch plug for pv power system
Product No. | B4G/B4H |
Rated voltage | TUV 1000V DC / UL 600V DC |
Rated current | 30A |
Suitable cable cross sections | 2.5mm2 ~ 10.0mm2 / 14AWG ~ 8AWG |
Terminal size | Φ4.0mm |
Test voltage | DC 8KV 1min |
Pollution degree | 2 |
Protection class | Class Ⅱ |
Terminal Material | Tinned copper |
Contact resistance | ≤ 5mΩ |
Insulation Materials | PPO |
IP rating | IP67(IEC 60529) |
Pull-out force | ≥ 50N |
Insertion Force | ≤ 50N |
Test temperature | -40℃~ +85℃ |
Flame Class | UL94V - 0 |
4 in 1 out 4-way perallel solar branch plug for pv power system
Our Service:
1.Quality:
l Bangzhao sends all the items with outgoing quality inspection report.
l We guarantee 100% good quality when the products are sent out of factory.
2.Shipping:
l Bangzhao ship to world wide;
l We ship the goods by the fastest way of EMS,UPS,DHL and TNT,reaching most countries within 7 days.
3.Return Policy:
l Once we shipped the products,our after-sale service will send you the tracking number;
l If your item is not as described or faulty when you receive it,we will replace it for you with no additional charge.
l If the item is found non-defective,the item will be sent back to the buyer at buyer’s expense.
