rubber vulcanizing machine, BELT VULCANIZING EQUIPMENT lower price in factory

FOB Price

USD $8,000 - $300,000 / Unit

1 Unit(Min.Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition:	New	Place of Origin:	Shandong, China	Brand Name:	JINRUNQI
Model Number:	1200*1200	Voltage:	as client's requirements	Power(W):	8.0KW
Dimension(LWH):	130021004000mm	Weight:	6800kgs	Certification:	ISO/CE
Warranty:	1 year	After-sales Service Provided:	Engineers available to service machinery overseas

The following pictures are diferent sizes press amchines for your reference:

The following is some infomation of standard rubber hydraulic press amchine/rubber vulcanizing press amchine.

Technical data:

Type	800*800	1000*1000	1200*1200	1500*1500
Nominal clamp mould force	1.6mn	2.0mn	2.5mn	3.15mn
Piston size	800*800	1000*1000mm	1200*1200mm	1500*1500mm
Number of cylinder	1	1 or 2 or 3 pieces	1 or 2 or 3 pieces	1 or 2 or 3 pieces
Piston diameter	¢360mm	¢400mm	¢450mm	¢500mm
Stroke of piston	300mm	300mm	300mm	300mm
Distance between hot plate	300mm	300mm	300mm	300mm
Unit area pressure of hot plate	2.5Mpa	2.0Mpa	1.8Mpa	1.5Mpa
Power	3.0KW	5.5KW	8.0KW	8.0KW
Overall size(LWH)(mm)	90016002500mm	110019003600mm	130021004000mm	160024504200mm
Weight	4000kgs	5800kgs	6800kgs	8000kgs
Close mould speed	≥6	≥6mm/s	≥6mm/s	≥6mm/s
Open mould speed	≥4	≥4mm/s	≥4mm/s	≥4mm/s
