Q35Y-25 combined universal steel punching machine

Specifications

1.Q35Y-25 combined universal steel punching machine
bined
3.dual cylinder
4.universal
5.ISO9001

Q35Y-25 combined universal steel punching machine



Products Special Benefits advantage Feature





1.The hydraulically driven double cylinder hydraulic ironworker is the up-to-date product in the domestic industry of punching and shearing machine.



2.The double hydraulic stations work independently.Due to 5 stations,multiple processing models are obtainable.



3.The whole machine is configured with standard punching station,shearing station of U and angle steel,shearing station of thick plates,cutting-off station of round and square as well as chamfering station.



4.Components for large hole punching,plate bending U and structural steel punching as well as chamfering od shutters and tubes are optionally available.



5.Manufactured by the advanced European technology,this machine is integrally structured by means of welding and treated with hightemperature quenching.Hence,it has high rigidity and strength.Additionally,since processed with special high temperature vacuum treatment,the tool life is largely extended.







Q35Y-25 combined universal steel punching machine is a machine tool integrating sheet metal cutting,  punching, plate  shearing, bending  and other functions. Having the virtues of easy operation, low consumption and low maintenance cost, it is designed via the latest technology and with laser positioning function to better cater for market demands. Besides, it is configured with automatic press device and temperate control radiator, and has become the first choice for metal processing of modern manufacturing industries(such as the metallurgy, bridge, communication, electric power, military and other industries).



The double cylinder Q35Y-25 combined universal steel punching machine enables shearing, punching  and die cutting of plates  and square,round ,U,angle and I steel as well as various structural steel materials. It is the first choice for mass processing of structural steel materials,and capable of bending the plates with the length of less than 500mm.The punching part is designed with a protective cover and the automatic stop gauge is mounted onto the machine back.We promise that all the components are provided in line with the highest quality requirements in safety,function,maintenance and performance aspects



Technical Specification of Q35Y-40 hydraulic metal punching machine



Specification	Q35Y-25	Q35Y-30
Punching station
Punching maximum capacity	35x25	38x30
Stroke Ram length	80	80
Deep Throat Standard	400(optional 600)	600
Punching Largest hole (Optional)	160	160
Working height	1142	1209
Shearing
Flat Plate Shearing Maximum	330x25	355x30
Flat Plate Shearing Maximum	600x16	600x20
Blade length	620	610
Angle Flange Trim Maximum 45°	100x14	100x16
Working Height	851	900
Angle Cutting Station
90°  Miter (True Interior /Exterior )	160x15	180x16
45°  Miter (True Interior /Exterior )	80x10	70x10
Working Height	1220	1220









Presale Service

We assist customers in well understanding the product information like features, functions and applications and so on. As for the detailed procuring information or drawings, our professionals will first conduct a careful examination and then recommend the most suitable machines or devise proper schemes for customers. We also provide free samples if necessary.



Service during the Sale

1. We are manned with professional salesmen and technicians to provide the information, technical support and the optimal solutions with high cost performance.



2. Based on the specific requirements of customers and the lead time, we will formulate a rigorous operation process. Through the close cooperation of Commodity Department, Sales Department, Technical Department and the Ocean Shipping Department, we are devoted to timely supplying customers with superior machines.



3. Generally, certain quantity of quick-wear parts will be delivered with the goods. The delivery deadline depends on the specific order, which is usually within 1 to 3 months.



After-Sale Service

1. One year warranty is provided.

2. Customers can send photos or samples for our confirmation once the parts are damaged within the one year warranty. If the parts are not damaged by misoperation, we will reply to customers within 48 hours and provide free parts for replacement. Besides, for the parts out of commission and beyond the

warranty, we only charge for the basic costs of parts.

3. We regularly follow up the service condition of products, and timely analyze and copy with the feedbacks. As for the disputes, we will figure out effective actions to reach mutual satisfaction.





 Re: This machine can punching ,shearing,notching, bending different kind of workpiece.
