Hydraulic guillotine shearing machine with E21 controller

Hydraulic guillotine shearing machine  with E21 controller

Technical characteristics

1. The frame is steel welded structure, have sufficient strength and rigidity, eliminate internal stress and high frequency vibration, to ensure the overall accuracy of the fuselage. Has a good rigidity, two cylinders fixed on the left and right columns (wallboard).

2 .Tool carrier for welded steel plate box-type structure, has a good rigidity, high-frequency vibration to eliminate internal stress, through the rear pivot point gap adjustment device for the center, and can quickly adjust the blade gap. Three-point support rolling clamping rail, and to maintain good accuracy, the tool carrier running smoothly, and can quickly adjust the blade gap.

  Configues list

hydraulic valve                     Bosch
pump                                    Shanghai
seal J                                    apan NOK
motor                                     Shuangta
Electric components            Schneider
Oil tank                                  Ma’ Anshan
blade                                     Shanghai
connector                              China

E200 NC system                    ESTUN

Specification and technical parameters:
