Infrared Remote Megapixel WIFI IP Bullet Camera For Yard Security Monitoring System

Specifications

1/4" 1.0 megapixel HD CMOS,
resolution: 1280x720, 0.05LUX low illumination.
IR_CUT dual optical filters auto switch.

• 1/4" 1.0 megapixel HD CMOS,
• resolution: 1280x720, 0.05LUX low illumination.
• IR_CUT dual optical filters auto switch.
• Hi3518 coding & ISP, H.264 compression.
• 25 frames, real time 720P, dual streams, built-in WEB, support ONVIF.
• Professional design for home security megapixel ir camera,
• small & beautiful & easy use.
• Private mold, excellent heat dissipation system got national patent,
• aluminum alloy casing.
• 2pcs imported SMD array IR LED (Finland LEDIL light lens),
• effective night vision distance 40-50m, excellent performance in dark environment.
• 3.0 Megapixel HD lens, 4mm / 6mm / 8mm / 12mm optional.
• Can add internal audio pickup,
• add POE module ($14) & WIFI module.
• Can add waterproof external TF card storage module.
• Can choose bracket or electrical bracket with pan & tilt function.
• Size: 140mm (L) x 75mm (W) x 62mm (H)
• Non-IR model optional.

1. Professional design for hd network camera, small, beautiful and delicate, best for home security.
2. Material: aluminum alloy, innovative patented heat dissipation structure, make hd camera can works well under high temperature.
3. 3 models: 2.4 megapixel, 1080P progressive scan; 1.3 megapixel, 960P progressive scan; 1.0 megapixel, 720P progressive scan.
4. Advanced digital signal processing technology, high brightness imported SMT IR source, show the best HD video effects in both day and night environment.
5. 3.0 Megapixel HD CS lens+ IR-CUT auto swith in day and night, 4mm, 6mm, 8mm, 12mm fixed focus lens optional.
6. 2pcs imported SMD array IR LED + Finland LEDIL light lens, effective night vision distance is 50m, excellent performance in dark environment.
7. Support 3D DNR, auto white balance, auto electronic shutter, auto electronic gain, real color reproduction, high resolution image.
8. Innovate design for build-in audio pickup (external type optional).
9. POE module and WIFI module optional. Can add waterproof external TF card storage module.
10. Exclusive innovation design, can choose our intelligent rotating bracket.
11. Support ONVIF protocol, can provide the SDK.



Type of this camera: Infrared remote megapixel WIFI IP bullet camera for yard security monitoring system, Megapixel HD IP camera, Megapixel ir camera, WIFI IP camera, IP bullet camera, wifi bullet camera, infrared ip camera, wifi camera, remote monitoring camera, camera for yard, yard monitoring, china ip camera, hd ip camera, ip ir camera, waterproof ip camera, monitoring system IP camera.



Model:		R-H234N	R-H334N		R-H534N
Camera	Imaging sensor:	1/4" CMOS progressive scan	1/3" CMOS progressive scan		1/2.8" SONY progressive
	Signal system:	PAL / NTSC adjustable
	Scanning mode:	Progressive scanning
	Illumination:	Color 0.2 lux, black & white 0.05 lux, IR on 0 lux	Color 0.2 lux, black & white 0.02 lux, IR on 0 lux		Color 0.2 lux, black & white 0.02 lux, IR on 0 lux
	Lens:	Standard with 3 million pixel 4-12mm fixed focus CS lens
	Day and night  switch:	IR-CUT dual optical filters auto switch in day and night
	Electronic shutter:	Manual / auto ( adjustable, 1 / 25 ~ 1 / 4000 seconds)
	White balance:	Auto / manual
	DNR:	3D-DNR
	IR source:	2pcs SMD array light source+ Finland LEDIL light lens
	Effective night vision distance:	50 meters (measured value without light condition)
Standard compression	Image compression:	H.264
	Video bit rate:	128 Kbps -- 8 Mbps; CBR / VBR adjustable
	Audio compression:	G.711 / G.726
	Audio bit rate:	64 Kbps (G.711) / 16 Kbps (G.726)
Image	Max image size:	1280 x 800	1296 x 976		1984 x 1225
	Frame rate:	1920 x 1080 @ 30 fps; 1280 x 960 @ 30 fps; 1280 x 720 @ 30 fps; 704 x 576 @ 25 fps; 640 x 360 @ 25 fps; 352 x 88 @ 25 fps
	Image adjustment:	Through IE can adjust Saturation, brightness, contrast, sharpness
	Image mirroring:	Horizontal mirroring, vertical mirroring
	Scene:	Auto, indoor, outdoor
	Digital enlarge:	Can achieve through NVR, P2P hd monitoring management software
Function	Storage:	Support TF card storage
	Interface protocol:	ONVIF
	Support protocol:	TCP / IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1x, QoS, IPv6, Bonjour (SIP, SRTP optional)
	Intelligent alarm:	Motion detection, mask alarm, network cable break , IP address conflict, storage card is full, storage device is wrong
	Audio pickup:	Can add internal audio pickup, also support external audio pickup
	POE power supply:	Support POE power supply (optional), internal and external type
	WIFI:	Support WIFI function (optional)
Interface	Communication interface:	1pc RJ45 10M / 100M Adaptive Ethernet port
Basic parameter	Power input:	DC 12V±10% / POE
	Power consumption:	1W (IR off) / 5.5W (IR on)		1.1W / 5.6W (IR on)
	Work environment:	-35°C ~ 60°C, humidity is less than 95% (no condensation)
	Size:	140 mm x 75 mm x 62 mm
