Home > Products > Induction Forging > Low price induction forging heater for bolts
Low price induction forging heater for bolts
- 500 Set / Sets per Month
- Shanghai Qingdao Tianjin Guangzhou or as you request
- T/T L/C D/P D/A Credit Card PayPal
- 50KW steel bars induction heating forging furnace
- Auto feeding steel bars induction forging furnace
- IGBT Medium frequency used induction heating equipment
- Square or rounds steel billet hot forging machine
- Medium frequency rods forging induction billet heater
- Billet forging furnace medium frequency induction heating power supply
Product Details
Condition: | New | Place of Origin: | Henan, China | Brand Name: | Yongda |
Model Number: | WZP-160 | Voltage: | 320-420V | Power(W): | 3-85KW |
Dimension(L*W*H): | main machine 740*403*895mm | Weight: | 120KGS | Certification: | ISO9001:2000 |
Warranty: | 12 months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Low price induction forging heater for bolts
Features of induction heater
1, my company transistor (IGBT) high frequency power-saving than vacuum tube up to 40-60%, saving 60%, external support facilities to reduce investment by 75%.
2, a unique cooling circulation system, ensure that the equipment 24 hours of continuous work.
3, small size, light weight, easy to move, no million-volt high-voltage danger, safe operation.
4, high reliability, easy to maintain and improve the over voltage, over current, overheating, lack of, water and other self-protection.
5, use large scale integrated circuit digital automatic control, with manual, automatic, semi-automatic, and the lack of heat insulation of cold sub-time control functions.
6, automatic frequency tracking, stepless power adjustment, easy to use, 10 minutes to learn to use.
7, the company has a complete sales service system and the treatment of professional engineers, to ensure that you have no worry about technology or service.
Technical parameters of induction heater for bolts
Model | WZP-160 |
Work power | 3 phase 380V+/-10%, 50-60HZ |
Input voltage | 320V-420V can be changed, depend on your country's electric power |
Input current | 6-160A |
Input power | 3-85KW adjustable stepless |
Oscillation frequency | 10-50KHZ also can be changed, depend on your work pieces size |
Size of generator | 740*403*895mm |
Size of transformer | 735*490*465mm |
Weight of generator | 55kgs |
Weight of transformer | 74kgs |
Cooling water pressure | 0.3 MPA |
Control panel of WZP-85KW induction heater
Application of induction heater
1, Induction forging, hot forming
A, all kinds of standard parts, fasteners, machinery parts, hardware tools, straight shank twist hot upsetting, hot.
B, metal heat annealing. Such as: tensile steel tube, pipe, smashed head; wire, heating wire nail; stainless steel annealed, rose type.
Steel bars induction heating for forging
Railway elastic steel strip induction heating for forging
Step 1
Step 2
Induction coils ,tailor-made, according to size of your work pieces.
Debugging machine workshop
1. Reply your inquiry within 24 working hours
2. Experienced engineer instruct and sales communicate with you in fluent English.
3. According to work pieces specifications, heating requirements, propose best solutions,also reference your ideas.
4. Machine details and working video link for your reference
5. Competitive price ,compare with the same industry
6. Production: strict quality standard, to produce machine and induction coils.
7. Debugging machine and only good machine will be sent.
8. Tracking goods shipping and provide bill of lading,invoice,packing list and other documents what you need
9. Provide install and technology instruction by sending drawings, email, or telephone,video.
10.If you need, will arrange one engineer to your place,instruct install machine and training operators.
11.Excess warranty period(12 months warranty), you can buy the spare parts from us with special discount price.
12.Provide long-terms technical support
Packing for induction forging heater
1.Two wooden cases (plywood) or cartoon, as you request.
Inside,will be filled with plastic foam,for waterproof and shockproof.
2.Accessories: induction coils,foot switch and installing and operating instructions
Shipping: by sea LCL(less than container load) or by air.
What’s your MOQ? | Any quantity of machine will be accepted. MOQ:1 Set |
Which place your factory is located? | We are located in Shenqiu County, Zhoukou city, Henan Province ,China |
How far from Beijing? I think it is more closer to Shanghai | Our factory is near both and Shanghai. We have office in Zhengzhou, we can pick up you at Zhengzhou CGO airport,and then to our factory via expressway about two hours. |
We need to see some more videos for production line and also pictures of your factory, water drawing and panel drawing | Well, we have many videos show our customer’s machine working scene(Various of applications: forging,hardening, brazing, shrink fitting, melting and hot coating etc. According to your work piece processing requirements,) send you the corresponding video link or send by email. 2. Yes, we can provide you factory pictures and machine water connection and control panel details. |
Do you have quality certifications? | Yes, we got the ISO9001:2000 International quality management system certification in August,2001, |
How do you packing the machines? | Standard export wooden cases(plywood) Usually every set machine will be used two wooden cases: one for packing induction heating generator, one for packing transformer. Inside will be filled with plastic foam for waterproof and shockproof |
More questions….? | Updating… |
To dear buyer:
In order save time and improve communicate efficiency,please kindly also tell us specifications of your work pieces and heating requirements:such as heating temperature, time requirments(output per hour),local or whole parts heating, application/purpose etc.
So that we will recommend you suitable machine model as soon as possible.
If you know little about induction heating equipment,it doesn't matter,please direct send us inquiry. Let us help you !
Thanks for your reading ! Welcome to contact us !
