micro powder mill machine for barite micro material gridning

FOB Price

USD $5,000 - $5,000 / Set

1 Set(Min.Order)

Supply Ability 30 Set / Sets per Month
Port guanghzou
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Type:	Grinder	Product Type:	Other, food, ore, herba, etc
Place of Origin:	Sichuan, China	Brand Name:	JSDL	Model Number:	JSDLRM
Voltage:	220v/380v	Power(W):	0.75KW	Dimension(LWH):	subject to custmer`s requests
Weight:	different models different weight	Certification:	CE,ISO	Warranty:	12 month
After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

micro powder mill machine for barite micro material gridning

Product Description

working principle:

the raw material is crushed by jaw crusher to the size required, then elevated into a hopper from which the material is transported through the electro-magnetic vibrating feeder evenly and continuously into the grinding chamber for powder-processing.

The rollers oscillate outward to press the ring because of the centrifugal force and the shovel scoops up the materials, send to the middle between the ring and rollers to accomplish the grinding.After grinding, the rough materials will be recycled by the air from the fan back into the grinding chamber for regrinding and the fine powders are blew into the cyclone and poured out through the output-powder pipe as the final products.

Features:

1. High efficiency and low energy consumption.

2. Accept different raw material size.

3. Dust extraction is up to the national relative standard.

4. Good stability and free from noisy pollution.

5. Good sealability.

well done powders:

techinical data:

Type/data/name	JS1410	JS2115	JS2615	JS2715	JS3016	JS3216	JS4116
Max feed size	10-15	10-20	10-20	10-20	10-25	20-25	20-30
Raw material size	0.125-0.044
Gross output(T)	0.5-8	1-18	1.5-20	2-28	3-35	6-50	6-66
Center shift speed(r/min)	280	160	162	162	160	140	103
Inner diameter of grinding ring(mm)	435	630	780	820	910	970	1280
Mainframe power(kw)	7.5/6	15/8	18.5/8	22/8	30/8	37/4	75/4
Fan power(kw)	5.5/2	11/4	15/4	1835/4	22/4	30/4	55/4
Analyzer power(kw)	1.1/2	2.2/6	2.2/6	2.2/6	2.2/6	5.5/4	7.5/4
