LED light strip waterproof with Double side glue-30leds/meter

FOB Price

USD $1 - $5 / Meter

100 Meters(Min.Order)

Supply Ability 10000 Meter / Meters per Month
Port Xiamen
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

LED Light Source:	SMD5050/SMD35281	Type:	Flex LED Strips	Input Voltage(V):	DC12V
Lamp Power:	14.4W/M	Lamp Luminous Flux(lm):	18-20lm/led	Color Temperature(CCT):	2700-7000K
Working Temperature(℃):	-40, 60	Working Lifetime(Hour):	50000	Lamp Body Material:	Aluminum
Brand Name:	Genilight	Model Number:	GLT-F3528X15DSW-12(24)

Product Description

LED light strip:

LED strip adopt high brightness LEDs as light source and high quality flexible PCB, every 3-LED is a group, can be cut and connectted. Outer adopt high quality materials as waterproof cover, it can prevent UV, water and dust, firmed by back adhesive 3M tape, The avalibale colors are red, green, blue, yellow, white, warm white. RGB. Widely used for architechtural decoration lightings, sign lightings and so on.

Features:

1. LED: SMD5050/SMD3528 LEDs
2. Voltage: DC 12V/24V
3. LED quantity: 20/30/60/90/120PCS/M
4. Length: 5m/roll
5. Size: 5000*8/10mm
6. Beam Angle: 120degree
7. IP Rank:Not waterproof, waterproof IP65 single side glue,waterproof IP67 silicon tube,waterproof IP68 double side glue.
8. Safty, no pollution
9. The light is even, soft, and comfortable
10. Long Life span: Over 50000 hours
11. Available color: White/warm white/red/green/blue/yellow/RGB
12. Color of PCB: Yellow/white

Specification:

NO.	Item No.	Color	LED type	LED qty/meter (PCS)	Size(MM)	Power (W/M)	IP Grade	Packing
NO.	Item No.	Color	LED type	LED qty/meter (PCS)	Size(MM)	Power (W/M)	IP Grade	Packing
1	GLT-F3528X30X-12	W/WW/CW/R/G/ B/Y	SMD3528	60	5000*8	4.8	IP33/IP65/IP68	5m/Roll
2	GLT-F3528X60X-12	W/WW/CW/R/G/ B/Y	SMD3528	120	5000*8	9.6	P33/IP65/IP68	5m/Roll
3	GLT-F3528X120X-12	W/WW/CW/R/G/ B/Y	SMD3528	240	5000*8	19.2	P33/IP65/IP68	5m/Roll
4	GLT-F5050X15X-12	W/WW/CW/R/G/B/Y /RGB	SMD5050	30	5000*10	7.2	P33/IP65/IP68	5m/Roll
5	GLT-F5050X30X-12	W/WW/CW/R/G/B/Y /RGB	SMD5050	60	5000*10	14.4	P33/IP65 /IP68	5m/Roll
6	GLT-F5050X60X-12	W/WW/CW/R/G/B/Y /RGB	SMD5050	120	5000*10	28.8	P33/IP65 /IP68	5m/Roll
7	GLT-F5630X15X-12	W	SMD5630	30	5000*10	15	P33/IP65 /IP68	5m/Roll
8	GLT-F5630X30X-12	W	SMD5630	60	5000*10	30	P33/IP65 /IP68	5m/Roll

Picture:

Waterproof IP:

Packing:

Applications:

1. architectural decorative lighting
2. archway, canopy & bridge edge lighting
3.amusement park, theater & aircraft cabin mood lighting
4.emergency hallway lighting
