API 5D Hard Banding Drill Pipe, Seamless Steel Drill Pipe with high quality and factory price

Name: API 5D Hard Banding Drill Pipe, Seamless Steel Drill Pipe with high quality and factory price
Brand: Zhongshi
Availability: InStock

FOB Price

USD $200 - $1,500 / Ton

10 Tons(Min.Order)

Supply Ability 1000 Ton / Tons per Month
Port Qingdao Tianjin port
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Henan, China	Brand Name	Zhongshi
Model Number	2-3/8'', 2-7/8'', 3-1/2'', 4'', 4-1/2'', 5'', 5-1/2'', 6-5/8''	Type	Drill Pipe
Machine Type	Drilling Tool	Certification	API
Material	Carbon Steel	Processing Type	Forging
Use	Well Drilling

Product Description

API 5D Hard Banding Drill Pipe, Seamless Steel Drill Pipe with high quality and factory price

1) Standard: API Spec 5D

2) API and ISO certified

3) Specification: 2-3/8'', 2-7/8'', 3-1/2'', 4'', 4-1/2'', 5'', 5-1/2'', 6-5/8''

4) Steel Grade: E75, X95, G105, S135

5) Upset Form: EU, IU, IEU

6)Description :

This type of drill pipe have optimal bearing design, it can be working stably in high WOB, and the qualtiy tungsten carbide inserts on cone and the gauge make a good wear resistance, largely extending the working life of bits. It is suitable for medium to hard formation.

7)Features:

a.High precision in size and shape
b.Good low temperature toughness
c.Excellent comprehensive mechanical properties
d.High connection strength and sealability
e.Large inside diameter of tool joint
f.High torque resistance
g.High fatigue strength and long fatigue life

8)Internal Coating Feature:

a.High abrasion resistance and low friction factor
b. Good adhesion and flexility
c. High application temperature and pressure
d. High hardness and impact resistance
e. Good corrosion resistance

9) Parameter

Spec	Weight	Flat-end Weight		External Diameter D		Wall Thickness t		Grade	Upset Type
Spec	Weight	lb/ft	Kg/m	inch	mm	inch	mm	Grade	Upset Type
2-3/8''	6.65	6.27	9.33	2.375	60.3	0.28	7.11	E,X,G,S	Upset
2-7/8''	10.4	9.72	14.47	2.875	73	0.362	9.19	E,X,G,S	Upset
3-1/2''	13.3	12.32	18.34	3.5	88.9	0.368	9.35	E,X,G,S	Upset
3-1/2''	15.5	14.64	21.79	3.5	88.9	0.449	11.4	E,X,G,S	Upset
4''	14	12.95	19.27	4	101.6	0.33	8.38	E,X,G,S	Int Upset
4-1/2''	16.6	15	22.32	4.5	114.3	0.337	8.56	E,X,G,S	Int-Ext Upset
4-1/2''	20	18.71	27.84	4.5	114.3	0.43	10.92	E,X,G,S	Int-Ext Upset
5''	19.5	17.95	26.7	5	127	0.362	9.19	E,X,G,S	Int-Ext Upset
5''	25.6	24.05	35.8	5	127	0.5	12.7	E,X,G,S	Int-Ext Upset
5-1/2''	21.9	19.83	29.52	5.5	139.7	0.361	9.17	E,X,G,S	Int-Ext Upset
5-1/2''	24.7	22.56	33.57	5.5	139.7	0.415	10.54	E,X,G,S	Int-Ext Upset
