cnc 1325 wood carving machine,marble carving cnc machine italy,stone router 3d stone carving cnc routersDTS1325

FOB Price

USD $4,800 - $7,530 / Set

1 Set(Min.Order)

Supply Ability 90 Set / Sets per Month
Port Qingdao Port China
Payment Terms:T/T

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Shandong, China	Brand Name:	DragonTech	Model Number:	DTS1325
Condition:	New	After-sales Service Provided:	Engineers available to service machinery overseas

Packaging Details

Wooden case

Product Description

cnc 1325 wood carving machine DTS1325

Applications:

Dragon Tech stone CNC Router is professional for tombstone, door frame, pillar, fireplace, summerhouse profiling and so on. High precision and high speed.

Options:

Diving system:stepper system, Panasonic/Yaskawa/Delta servo system

Spindle: HSD, Colombo, Chinese GS/GDZ/HQD spindle

Inverter: Delta inverter,Fuling inverter

Control system: DSP, Syntec, Mach3, Ncstudio

Can equipe rotating axis, liubricating system, mist cooling system, and so on.

http://youtu.be/XqXA4LFsSWg

http://youtu.be/R5tdVQhK7XY

http://youtu.be/gFFCp_tUApU

http://youtu.be/vpio8Xq_BrQ

http://youtu.be/7jcLZQuQN6E

http://youtu.be/5_cfe1K9QmE

http://youtu.be/z9PSrnx8vKA

http://youtu.be/C_df6-F6Xvk

http://youtu.be/OEUzbA0RDKE

http://youtu.be/A2-AO_WknL0

http://youtu.be/teGDfj9iWXk

NO.	Description	="top"> DTS1325
1	X,Y,Z working size	13002500300mm
2	Working table	PVC and T-slot aluminum table, water tray
3	Gantry	Steel gantry
4	Lathe structure	Welding steel tube frame
5	Transmission system	Ball screw and HIWIN linear Rails for X/Y/Z
6	Driving system	Stepper motor and drivers
7	Repositioning accuracy	±0.03mm
8	Max. travelling speed	20000mm/min
9	Max. working speed	3000mm/min
10	Spindle and collet	4.5kw HSD spindle
11	Spindle speed	0-18000RPM
12	Working voltage	AC380V/3ph
13	Max. consume power	8.5kw
14	Operating system	DSP system
15	Command code	G code(uoo, nc, mmg, plt)

P.S.

All the parts of machine can do some changes to meet your requirements ,such as the motor (step motor or servo motor ), spindle (air cooled or water-cooled ),inverter(DELTA or FULING) and the table of the machine also can be customized and so on .
