GTW 4-12 CNC stirrup bender up to 12 mm steel rebar

Name: GTW 4-12 CNC stirrup bender up to 12 mm steel rebar
Brand: ELLSEN
Availability: InStock

FOB Price

USD $20,000 - $25,000 / Set

1 Set(Min.Order)

Supply Ability 10 Set / Sets per Month
Port Qingdao Shanghai Tianjin Ningbo

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Condition:	New	Place of Origin:	Henan, China	Brand Name:	ELLSEN
Model Number:	GTW4-12	Machine Type:	Other, Steel bar cnc stirrup bender	Raw Material:	Steel Bar
Material / Metal Processed:	Carbon Steel	Power:	Cnc	Automation:	Automatic
Extra Services:	Cut To Length	Certification:	ISO 9001:2000	After-sales Service Provided:	Engineers available to service machinery overseas

Product Description

GTW 4-12 CNC stirrup bender up to 12 mm steel rebar

Product Overviews

Exhibition of stirrup bending machine

Production capacity	Single wire	Φ4– 12 [mm]
	Double wire	Φ4 – 10 [mm]
Production capacity		200tons ( 10hours/day and 6days/week)
Max. bending angle		±180° [double direction]
Max. bending speed		1200 [°/sec] (1100pics/h)
Max. pulling speed		110 [m/min]
Mandrel diameter		Φ25 – Φ32 [mm]
Max. length of the stirrup side		1050/1220 [mm]
Min. length of the stirrup side		50 [mm]
Length tolerance		± 1 [mm]
Bending tolerance		± 1°
Average air-compressed consumption		5 [l/min]
Rated power 2 servo motor		13.5+7.5 [KW]
1 Brake motor		3 [KW]
1 Motor for air pump		3 [KW]
Average electric power consumption		5 [KW]
Labeled electric power		27 [KW]
Overall machine weight		2100 [Kg]
Overall dimension		3650 × 1050 × 2015mm

If you are interested in stirrup bender,Click here:"Send enquiry"

Product Description

Brief introduction of stirrup bending machine

Brief description

Stirrup Bending Machine is a new generation steel bar bending machine. it is applicable to Φ4-Φ12HRB335 hot rolled ribbed steel bar,HRB400 hot rolled ribbed steel bar, plain round bar, and cold rolled ribbed steel bar. With the quality of standard size , high speed and mechanics performance stability. It is widely used with Steel works , rebar process workshop and Steel welding net factory.

Advantage & Feature

1. Automatic wire feeding system ( CNC );

2. Large storage capacity can save 500 processing geometric graphics, high degree automation;

3. Automatic double wire intake system, high processing efficiency;

4. High quality special material and high treatment to make straightening wheels, traction wheels, the metering wheel, longer life with lower operating costs;

5. Aerodynamic design observation door, easy adjustment and maintenance, and more security and fast.

Product details of stirrup bending machine

Products show of small stirrup bending machine

Technical parameter of small stirrup bender
Model		GF20	G525	GF28	GF32
Bending diameter	mm	Φ4-Φ18	Φ4-Φ22	Φ4-Φ28	Φ32
Bending speed of main axis	times/min	25-30	25-30	25-30	18
Motor power	KW	2.2	3	3	3
Weight	KGS	100	170	220	250
Machine dimension	mm	850x550x820	850x550x850	950x550x850	670x670x800

If you are interested in small stirrup bender,Click here:"Send enquiry"
