High quality digital Pressure and temperature indicator

Specifications

Pressure and temperature indicator
1High quality reasonable price
2China factory fast delivery
3High stability high accuracy



Description

it is small in volume, light in height and save power and completed function and reliable task.  can measure the pressure and temperature at the same time  .Flexible and easy to use. It can be widely used not only in situation of display and autocontrol in hydraulic pressure, oil, plastics, latex, printing and dyeing, textile industry but also can be compound with resistance strain guage press sensor of other manufactory. If it is used with our model PT124- series melt pressure transducers and normal pressure transducer. As high precision pressure of measure and control, it can be set upper limit and lower limit alarm.It has the indicator light on alarm,relay touch output control peripheral equipment, high precision of voltage output module, current output module and relay output control modult for user to choose.The machine adopts the operation of humanism,so it is easy for operating.

  Specification

(1)	Display	Dual 4-digit Green and Red LEDs
(2)	Resolution	0.2% FSO ± 1
(3)	LEDs	Out, Alarm-1, Alarm-2, CALibration
(4)	Input Sensibility	2.5mv/V or 3.3 mv/V (automatic selection)
(5)	Sampling Speed	20 per second
(6)	Excitation Voltage	+9 VDC (output to transducer)
(7)	Termocouple	J,K,E optional
(8)	All Output Relays	Relay 220V 1A
(9)	Retransmission	4~~20 mA standard current loop
(10)	Communication	RS-485 MODBUS( PY500 Only)
(11)	Alarm Range	0001 9999 PSI or Bar (configurable)
(12)	Temperature	0 - 55°C
(13)	Humidity	<= 80% RH
(14)	Calibration	80% FSO (Full Scale Output)
(15)	Power Supply	110/220VAC or +24VDC (designated while purchasing)
(16)	Size	96mm×96mm×100 mm (W x H x D)
(17)	Panel Cutout	92mm x 92mm (W x H)
(18)	Weight	400(Maximum) grams



Price, Package and Service

1, Price : FOB SHANGHAI

2, Payment: 100% T/T in advance .

3, Packing : standard export packing , including instructions and certificate

4, Leading time : 7-10 working days.

5, OEM avaliable

6, Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder

7. 7 days free replace & 1 year free repair for quality warranty
