4-20mA PT100 temperature transmitter
- 6 Piece / Pieces per Month
- Shanghai
- Credit Card PayPal
You May Like
Product Details
| Place of Origin | Shanghai, China | Brand Name | ZHYQ | |
| Model Number | WR-203 | Usage | Industrial | |
| Theory | Temperature Transmitter |
Product Description
Specifications
It can be widely used in automation temperature control system, such as metallurgy, machinery, petroleum, electricity, chemical
4-20mA PT100 temperature transmitter
Description
This series products is used to measure the temperature of the surface of liquid, steam, gas and solid under -50 to +300°C. It is suitable for temperature measurement in water supply, hydraulic pressure, cooling, heating system industry and automatic control.
Specification
Model | WR-203 |
Temperature range | -50 to +300°C |
Output | 4-20mA (2-wire) |
Power supply | 10 ~30VDC |
error | 0.1%FS, 0.3%FS, 0.5%FS |
Media compatibility | 316L stainless steel |
Pressure connection | Thread |
Protection tube | Stainless steel, 5mm, 6mm and 8mm dia. |
Insert length (L) | 30mm <L<500mm |
Sensing element | PT100 temperature sensor |
Electrical connector | DIN43650 (IP65) |
Price, Package and Service
1, Our quotation is always valid for you if there is no world market unrest.
2, Receiving your new inquiry, the infos of products & the best price will be provided you asap.
3, Replacement and repair if there is quality problem within 7-15 working days.
4, Port: Shanghai.
5, Payment: T/T.
6, OEM available
7, Delivery time is 7-10 working days.
8, All goods will be fully checked by our QC.
9, Package: The goods will be put into the packing box with instructions and certificate of quality first. Then we pack them into the box with polystyrene foam avoiding the damage to the products.
10, Shipment: Express (FedEx, DHL, UPS & TNT) or forwarder.
