MSO4054 Digital Oscilloscope 500MHz 4,16 digital channels

Specifications

MSO4054 Digital Oscilloscope 500MHz 4,16 digital channels



MSO4054 Digital Oscilloscope 500MHz 4,16 digital channels

Product:

features Analog channel bandwidth of 100 MHZ, 200 MHZ, 100 MHZ, 500 MHZ

Realtime sampling rate analog channel up to 4 g Sa/s; Digital channel 1 g Sa/s (the oledata.mso)

Standard storage depth 140 MPTS analog channel, digital channel 28 MPTS (the oledata.mso)

2 or 4 analog channel; 16 digital channel (the oledata.mso)

Waveform capture rate was 110000 per second

waveform With as many as 200000 frames of hardware real-time waveform uninterrupted recording and waveform analysis

Original UltraVision technology

Rich trigger and bus decoding function (analog and digital channels)

Low noise, the minimum vertical gear up to 1 mV/div

Rich interface: USB Host and Device, LAN (support LXI - C), VGA, AUX, USB - GPIB (optional)

A novel sophisticated industrial design, convenient operation

9 inches WVGA 256 grayscale display



MSO/DS4000 Series Digital Oscilloscope

MSO/DS4000 Series is the new mainstream digital scope to meet the customer's applications with its innovative technology, industry leading specifications, powerful trigger functions and broad analysis capabilities.
