Brand New HF-10K digital Force Gauge with S external sensor 10KN push pull tester

Name: Brand New HF-10K digital Force Gauge with S external sensor 10KN push pull tester
Brand: Graigar
Availability: InStock

FOB Price

USD $430 - $500 / Piece

1 Piece(Min.Order)

Supply Ability 3000 Piece / Pieces per Month
Port shenzhen
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

Graigar

Model Number

HF-10K

Product Description

Specifications

Brand New HF-10K digital Force Gauge with S external sensor 10KN push pull tester

Product Description

The force gauge has advantages of high precision, easy operation and carry. What's more, it has

kinds of testing modes, convenience for conner and it can store and input data to computer for

statistical analysis as well as constitutes testers with different functions, combinating with test-beds and clamp. Users can input local acceleration of gravity value to make test more precise.

Functional characteristics:

1. High precision and high resolution.

2. Five testing modes and three display methods for selection--enhancetesting efficiency to the maximum extent

3. N (Newton), kg (Kilogram) and lb (Pound) three measuring units for selection and conversion.

4. Setting function of gravity acceleration---User can input at your option the accurate value of gravity acceleration at the using place so as to

make the testing and unit conversion be more accurate.

5. Function of peak value maintaining. Maintain the display of peak value until manual zero clearing.

6.Automatic peak function. Maintain the display of peak value for 2 seconds and then release automatically.

7.Max and min and comparison value can be set for statistic analysis. The buzzer will alarm if

exceeding comparison value.

8. Data storage function. 896 testing values can be stored.

9.Data output function. The data can be input into computer through data line for various analyses.

10. Environmental protection. The device will automatically stop if no operation within 10 minutes.

11. High quality chargeable power supply. The charging voltage is avai-lable from 100V to 240V, which can accommodate most areas in domestic and at abroad. It has

also protection functions for short circuit, leakage and overload.

12.2 sets mounting dimensions, it is applied for most testing platforms domestically and easy for

users to install it to platform.

13. Special testing function of make-break ability of switch contact to make the make

break testing be more accurate.

14. 6 digits large screen display.

15.Synchronous measuring softwarecan connect computer measuring, the computer display

measuring graph and the detailed testing records,and can preserve, print ,make analysis,input

speed, area, displacement, pressure. ( chosen functiondetails see CD data )

16. Contact control signal outputsetting comparative value,when the Measuring value is over

comparative value, output signal control circuit Breaker's make-and break, thus realize the function of stop electromotor, And control automatically; it is also can be

used for realize other control Functions, for example input signal to plc to realize automatization.

Also it can set signal output mode, for example output signal at some Measuring range. There is

a jack on the side of apparatus can put one Side of connection line to secondary jack, and the

other side in the jack On the testing machine which is produced by our company, thus it can

realize function of stop electromotor automatically when the measuringValue is over comparative

value. The comparative value can set by himself.

17. Negative phototropism functionuse key-press or apparatus is stressed,the negative photo tropism would light automatically, it will close

negative phototropism if 10s non-operation; it also can press "setting" key 6 times ,enter 'light" condition, choose "NO" to close

negative phototropism, chose "YES" to start the function automatically.

18. LCD overturn display press "print" key can make the value reverse 180°,convenience for looking

the measuring value from different angle.

19. Reset quickly when system halted accidentally install reset key on the side , then press the key

swith forcely can make power off.

Force gauge mode specification sheet

Model specification sheet of force gauge with inner sensor

Model specification		HF-2	HF-5	HF-10	HF-20	HF-50	HF-100	HF-200	HF-500	HF-1000
Peak load value	N	2	5	10	20	50	100	200	500	1000
	kg	2	0.5	1	2	5	10	20	50	100
	lbs	0.44	1.1	2.2	4.4	11	22	44	110	220
load division value	N	0.001	0.001	0.01	0.01	0.01	0.1	0.1	0.1	1
	kg	0.0001	0.0001	0.001	0.001	0.001	0.01	0.01	0.01	0.1
	lbs	0.0001	0.0001	0.001	0.001	0.001	0.01	0.01	0.01	0.1
Indication error		0.50%
Unit		N / kg / lbs
Data interface		Rs232 nine-hole socket
Power		rechargeable batteries, charger(charging voltage 100V-240V)
Sensor structure		S-tye sensor with high precision (inner sensor)
Ambient temperature		5° C~35° C
Tansport temperature		-10° C~60° C
Relative humidity		15%~80%RH
Working conditions		No hypocenter and corrosive medium
Gross weight		~2000g
Size		273 x 182 x70 mm

Model specification sheet of force gauge with external sensor

Model specification

HF2000

HF5000

HF10K

HF20K

HF50K

HF100K

HF200K

HF500K

HF1000K

Peak load value

2000N

5000N

10KN

20KN

50KN

100KN

200KN

500KN

1000KN

load division value

0.01KN

0.1KN

1KN

0.1kg

0.001Mg

0.01Mg

0.1Mg

0.1lbs

0.001Klbs

0.01Klbs

0.1Klbs

Indication error

±0.5%

±1%

Unit

N / (KN), kg / (Mg or t), lbs (Klbs)

Data interface

Rs232 nine-hole socket

Power

rechargeable batteries, charger(charging voltage 100V-240V)

Sensor structure

S-tye or column sensor with high precision (extenal sensor)

Ambient temperature

5° C~35° C

Tansport temperature

-10° C~60° C

Relative humidity

15%~80%RH

Working conditions

No hypocenter and corrosive medium

Gross weight

6 kg

9 kg

24 kg

36 kg

Size

280 x 200 x 170 mm

310 x 260 x 190 mm

Model specification	HF3000K
Peak load value	3000KN
load division value	1KN
	0.1Mg
	0.1Klbs
Indication error	±1%
Unit	N / (KN), kg / (Mg or t), lbs (Klbs)
Data interface	Rs232 nine-hole socket
Power	rechargeable batteries, charger(charging voltage 100V-240V)
Sensor structure	S-tye or column sensor with high precision (extenal sensor)
Ambient temperature	5° C~35° C
Tansport temperature	-10° C~60° C
Relative humidity	15%~80%RH
Working conditions	No hypocenter and corrosive medium
Gross weight	36 kg
Size	310 x 260 x 190 mm
