UNI-T UT311 Portable LCD Vibration Analyzer Tester Meter NDT Vibrograph Vibrometer With Acceleration Sensor in One
US$ 200 - 250
MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
UNI-T
Model Number:
UT311
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
AT-280 Coating Thickness Gauge Meter Portable Palm-size Wholeness Amphibious Type Without DamageUS$ 200 - 300MOQ: 1 Piece -
AT-260 Coating Thickness Gauges Portable Palm-size Wholeness Amphibious Type Without DamageUS$ 200 - 280MOQ: 1 Piece
-
AT-220F Coating Thickness Gauges Portable Palm-size Wholeness Vortex Method Detect Non-conductive Coating Without DamageUS$ 180 - 240MOQ: 1 Piece
-
Portable Palm-size Coating Thickness Gauge Meter AT-220 Magnetic and Non-magnetic Without DamageUS$ 150 - 210MOQ: 1 Piece
-
AT-230 Portable Palm-size Coating Thickness Gauges LED Magnetic Thickness Measurement Method Without DamageUS$ 150 - 210MOQ: 1 Piece
Place of Origin
Guangdong, China
Brand Name
UNI-T
Model Number
UT311
Usage
Vibration Testing Machine
UNI-T UT311 Portable LCD Vibration Analyzer Tester Meter NDT Vibrograph Vibrometer with Acceleration Sensor in One
Introduction
1. UT310 series handheld vibration meter is designed with acceleration sensor and digital measurement circuit. It’s mainly used in measuring the vibration of mechanical equipment, velocity, and acceleration. The measured data are compared with the national, international, corporate, machinery working standard to decide the condition (good, note or dangerous, etc.) of the machine(fan, pump, compressor, motor, etc.).
2. Can be widely used in mechanical manufacturing, electric power, petroleum chemical industry, metallurgy, aerospace and other fields. It’s the ideal measurement tool for purchasing inspection, operation monitoring and maintenance for the rotating machinery equipment.
Specifications
| Specifications | Range | Best Accuracy | |
| Model | UT311 All in one | UT312 Split style | |
| Vibration Acceleration(O-P) | 0.1-199.9m/s² | Frequency response:10-1500Hz,Amplitude error:≤±5% | |
| Amplitude linear error:≤2.0m/s²,≤±10%; >2.0m/s²,≤±5% | |||
| Vibration Velocity(RMS) | 0.1-199.9mm/s | Frequency response:10-1500Hz , Amplitude error:≤±5% | |
| Amplitude linear error:≤2.0mm/s,≤±10%; >2.0mm/s,≤±5% | |||
| Vibration displacement(P-P) | 1 - 1999μm | Frequency response:10-500Hz, Amplitude error:≤±5% | |
| Amplitude linear error:≤20um,≤±10%; >20um, ≤±5% | |||
| Functions | |||
| Data Hold | √ (auto data hold when releasing the measure key) | ||
| Low battery indication | √ | ||
| Auto Power Off | √ (auto power off 1 minutes after releasing the measure key) | ||
| Display Modes | Digital display | ||
| Battery Life | Continuous measuring time > 20 hours | ||
| Maximum Display | 1999 | ||
| General Characteristics | |||
| Battery | 6F22 9V battery | ||
| Product Colour | Red and Grey | ||
| Product Net weight | 230g (including battery) | ||
| Product Size | 185mm x 68mm x 30 mm | ||
| Standard Accessories | Battery, Holster | ||
| Standard Individual Packing | Gift Box, English Manual, Warranty Card. | ||
| Standard Quantity Per Carton | 20 Pcs | ||
| Standard Carton Measurement | 600mm×370mm×474mm | ||
| Standard Carton Gross Weight | About 5 Kg | ||
Accessories
Batteries, (not included)
Holster
