TASI 676 Digital Coating Thickness Gauge Painting Width 0 to 40mils Hi or Lo Storage 255 datas Ferrous and non-Ferrous

Name: TASI 676 Digital Coating Thickness Gauge Painting Width 0 to 40mils Hi or Lo Storage 255 datas Ferrous and non-Ferrous
Brand: TASI
Availability: InStock

FOB Price

USD $220 - $300 / Piece

1 Piece(Min.Order)

Supply Ability 500 Piece / Pieces per Month
Port shenzhen
Payment TermsT/T Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Brand Name

TASI

Model Number

TASI 676

Product Description

Specifications

TASI 676 Digital Coating Thickness Gauge Painting Width 0 to 40mils Hi or Lo Storage 255 datas Ferrous and non-Ferrous

GENERAL SPECIFICATIONS

Display: 3-½ digit liquid crystal display (LCD) with maximum reading of 1999.

Low Battery Indication: The “+ -” is displayed when the battery voltage drops below the operating level.

Measurement Rate: 1 second, nominal.

Operating Environment: 32°F to 122°F (0°C to 50°C) at < 75% R.H.

Storage Temperature: -4°F to 140°F (-20°C to 60°C), 0 to 80% R.H. with battery removed from meter.

Auto Power Off: 30 seconds without any operating.

Standby Consuming Current: Less than 15µA.

Hi/Lo Alarm function

Data storage capacity: 255

Battery: Standard 9V battery (NEDA 1604, IEC 6F22 006P).

Battery Life: 9 hours (continuity) typical (contain Back-lit).

Dimensions: 148mm (H) x 105mm(W) x 42mm(D).

Weight: Approx.157g (including battery).

Detectable Substrate Material: Ferrous metal (iron, steel) and Non-Ferrous metal (copper, aluminum, zinc, bronze, brass, etc.) .

ELECTRICAL

Thickness Range: 0 to 40.0mils (0 to 1000µm).

Display Resolution: 0.1mils/1µm.

Accuracy:

±4dgts on 0 to 7.8mils

±10dgts on 0 to 199µm

±(3%+4dgts) on 7.9mils to 40mils

±(3%+10dgts) on 200µm to 1000µm

Temperature Coefficient: ±0.1% of reading, whichever is greater, change in accuracy per °F/°C change in ambient operating temperature above 82.4°F/28°C or below 64.4°F/18°C.

Response Time: 1 second.

WARNING

ELECTROMAGNETIC FIELD INTERFERENCE

This instrument uses magnetic field method to measure the coating thickness on ferrous meta l base. If this meter was placed in the environment with 20mG (mini Gauss) or above, the accuracy would be affected.Suggest that the meter should to put far away fr om the interfered source at least 30cm.

Electromagnetic field strength: ( unit = mini Gauss)

Electromagnetic Source	0cm	30cm
Cellular Phone Charger	50 ~ 500	< 1
Notebook Power Supply	100 ~ 1000	< 5
LCD Display	10 ~ 100	< 1
Fan	100 ~ 1000	< 5
Reading Lamp	400 ~ 4000	< 10
Any product with coil inside should be considered.

Edited by ZACK
