Fiber Optical Multimeter -70~+3dBm Handheld Fiber Optical Power Meter + Fiber Optical Light Source 1310/1550nm GRF-03A/B

Fiber Optical Multimeter -70~+3dBm Handheld Fiber Optical Power Meter + Fiber Optical Light Source 1310/1550nm GRF-03A/B photo-1
Fiber Optical Multimeter -70~+3dBm Handheld Fiber Optical Power Meter + Fiber Optical Light Source 1310/1550nm GRF-03A/B photo-2
Fiber Optical Multimeter -70~+3dBm Handheld Fiber Optical Power Meter + Fiber Optical Light Source 1310/1550nm GRF-03A/B photo-3
Fiber Optical Multimeter -70~+3dBm Handheld Fiber Optical Power Meter + Fiber Optical Light Source 1310/1550nm GRF-03A/B photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
GRAIGAR
Model Number:
GRF-03A
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name GRAIGAR
Model Number GRF-03A

Fiber Optical Multimeter -70~+3dBm Handheld Fiber Optical Power Meter + Fiber Optical Light Source 1310/1550nm GRF-03A/B

GRF Handheld optical power meter is a compact and an easy-to-use testing instrument for optical fiber networks, which can be used for absolute optical power measurements as well as for relative loss measurements in optical fibers.

 Application

  • Telecom Maintenance
  • CCTV Maintenance
  • Comprehensive cable construction system
  • Optical instruments research and development
  • Optical communication education and lab testing
  • Other optical project

 Features

  • User self calibration function
  •  Comfortable LCD display and optional backlight LCD display supports night operation
  • Power measurements in dBm or mw and insertion loss in dB
  • Low battery consumption, more than 240 hours continual operation time for three 1.5V alkaline batteries
  • Optional 10 minutes Auto-off function



OPM Specification



Model

GRF-03A

GRF-0AB

Wavelength(nm)

(800nm to 1700nm )

Detector

InGaAs

Measurement Range (dBm)

-70~+3



-50~+26

Uncertainty

+5%

Calibrated Wavelength(nm)

850,980,1300,1310,1490,1550 (more calibrated wavelength can be optional)

Resolution(dB)

Linear 0.1% or Non-linear 0.01dBm

Optical Connector

FC/ Universal 2.5mm adaptor (FC/SC)

Power Supply

Alkaline Battery(3 AA 1.5V batteries)(without batteries)

Battery Operating Time

240 h with 1.5V Battery(3)

Operating Temperature(oC)

-10 ~ +60

Storage Temperature(oC)

-25 ~ +70

Relative Humidity

0 to 95% (non-condensing)



Dimension(mm)

172x82x33



Weight

400 g
