2015 Newest Design DCF-80 ELECTROMAGNETIC VALVE With High Quality

              2015 Newest Design DCF-80 ELECTROMAGNETIC VALVE with High Quality

Description:
DCF-80 electromagnetic valve can be used together with a gas leakage alarm to form a security system. When the gas concentration in the air reaches the alarming level, the gas alarm gives audible & visual alarming, and drives simultaneously the valve to shut off the gas supply so as to avoid continuous gas leakage, combustion and explosion..
Applications:
DCF-80 electromagnetic valve is used to shut off the gas supply when there is a gas leakage in your home.
Features:
Well airproofed,
Low power consumption
High sensitivity,
Reliable performance,
Small size and easy handle

Rated voltage for valve close: DC9~12V
Quiescent Working Current: 0A
Resistance of loop in valve-closed: 4.5Ω±0.5Ω Output: N.O
Diameter: G1/2(DN15)-G1(DN25)
Response Time: <0.3 sec
Operating Pressure: 0.5—200kpa
Operating Temperature: -15℃~50℃
Relative Humidity: ≤93%
Atmosphere Pressure: 86~106kpa
Diameter: G1/2”, G3/4”, G1”
