Newsurway New Product 8CH P2P D1 DVR H 264 with HDMI Output





Product Description



MAIN FEATURES :

  H.264 High Profile Compression,8CH 960P/ 720P/ 960H/D1

  Support Dual stream (Main stream for local storage, sub-stream for network transmission)

  Support Cloud service, P2P function, easy to do remote control

  Support Mobile phone view (Android iPhone iPad Blackberry Windows Mobile)

  Support Multi-browser, including Windows IEFirefoxChromeSafari

  CMS Software Supported

Motherboard Specification:

Model NO.

AVR-6608T

System

Operating system

Embedded LINUX operating system

Display

Operation interface

16 bit real color GUI interface support mouse operation

Display

1/4CH

Video

Video standard

PAL(625 lines,50fps);NTSC(525lines,60fps)

Compression

H.264(High Profile)

Display quality

Monitor:D1;VGA:1280*1024;HDMI(1920*960P)

Playback quality

960P/720P/960H/D1/HD1/CIF/QCIF

Record Resolution& Frame

PAL: 960P/720P/960H/ D1/HD1/CIF@100fps

NTSC:960P/720P/960H/D1/HD1/CIF@120fps

Playback Frame

PAL: 960P/720P/960H/ D1/HD1/CIF@100fps

NTSC:960P/720P/960H/D1/HD1/CIF@120fps

Hybrid Mode

DVR mode :4ch 720P ; NVR mode :2ch 720P+2ch 960P

Motion detection

192(16*12)detection area;can set multi-level of flexibility

Audio

Audio compression

G.711A

Record and playback

Record mode

Manual,alarm,motion detection,timing

Local playback

8CH  960P/720P/960H/D1

Video search

Time,date,event,channel search

Storage and back up

Space occupation

Video:CIF 4~5G/day*channel, D1 16~20G/day*channel;

Audio:691.2M/day*channel

Video storage

Local HDD ,Network

Back up mode

Network backup,USB portable HDD,USB DVD-RW

Network

Protocol

DHCP,PPPOE,FTP,DNS,DDNS,,NTP,UPNP,EMAIL etc

IE Browser

Windows IE ,Firefox ,Chrome ,Safari

CMS

Free use

Mobile Phone

Android iPhone iPad Blackberry Windows Mobile

Interface

Video input

8CH BNC

Video output

                        1CH VGA,1CH HDMI

Audio input

NO

Audio output

NO

Alarm input

NO

Alarm output

NO

Network port

RJ45 10M/100M  Ethernet port

PTZ control

NO

USB port

2*USB2.0

HDD port

1 SATA(each max support 3TB)

other

Language

English,Finnish,French,German,Greek,Italian,Japanese,Polish,Portuguese,Arabic,Farsi,Russian,Spanish,Thai,Turkish, etc

Mouse

Yes

Remote controller

NO(if you need, we can add for you)

Power

DC12V/2A

Dimension

250(L) x 235(W) x 45(H)











The specification is subject to change without notice.
