Specifications

MAIN FEATURES

Adopting New generation IR Array technology, long distance (more than 100m) and uniformity light

Driven by light sourcing constant current, runs steady, will not affected by temperature,longer IR Lifetime, 5 to 10 times than traditions LEDS

IR light changes automatically with zoom, strong and weak can be set,

Flashlight phenomenon and white image problem both being solved.

Built-in IR sensibility all-in-one

 horizontal Pan 360°consecutive movement, Vertical -2°-95°, Tilt 180° automatic movement. up to speed 200°/s. panoramic monitoring.

 256 preset positions. The preset accuration is less than 0.05°

 6 tour groups, each of which can be set with 18 preset positions

4 scan, can record 5-500mins each scan

Many types of auto scan for choice, and speed can be set by built-in menu.

you can set up 4 types of movement when no person cooperate , preview Preset Positions, run Tour Groups, and auto scanning.

 Menu screen in chinese

 It displays control protocol, address code, Baud Rate and screen menu when starting up

 Shortcut function key can be invoked and amended.

Address, protocol and baud rate can be revised.

 Broadcast address function.

can display temperature, coordinate and time

 preview Preset Positions

driven by a precise stepper electric motor, runs smoothly, reacts quickly and locates positions accurately.

EEPROM EEPROM data storage, the data will not lost when power off.

With RS485 to control, support many kinds of protocol

Full Aluminum Housing, better heat dissipation

IP66 all-environments protection, built-in auto constant temperature

Simple install interface, convenient and shortcut

 Wall Mount Bracket (Ceiling bracket is optional)
