70T Large Sized Tube Ice Evaporater 2012(70Ton/Day)

Specifications

1Edible Tube Ice Machine
2Stable of production
3Easy for storage
4High reliability
5Certification:CE,ISO9001.ISO14001

Tube ice machine Evaporator application
1 Human consumption ice plant
2 Port ice plant
3 Coffee shop,bar,and hotel,etc
4 Supermarket,convenienience shop and restaurant,etc
5 Aquatic products and food fresh preservation
6 Logistic fresh preservation
7 Cgemical and concrete projects

Tube ice machine Evaporator work conditions
Power supply:  Full electric system complying with the general international standard
Ambient temperature:  33°C
Water supply temperature:  20°C(water quality should be pure,Water filter and softening is suggesteded for places with hard water quality).)
Tube ice specification:  φ22,φ29,φ35,φ38 and φ41standardard tube ice outer diameter,inner diametr 3mm-15mm
Limit work comditions(variable wiork condions):  Ambient temp.:  5°C~40°C;  Water suppl:0.5°C~30°C.
Refrigrant:  R22,R404A,R507A,R717
Compressor brand:  Bizer/carrier,or designated by customer

Material for customers to choose
Evaporator freezing surface
1 SUS304
2 SUS316L
3 Q345 Chrome-plated


Tube ice machine Evaporator feature
1 High reliability and low fault failure
——80% components of the tube ice maker system are world famous brand. Through decades of research and practice, SNOWKEY products can run continuously without fault and keep good run and stable ice output even in ambient temperature 5°C-4O°C. Special designed machine can even allow normal run in the most atrocious conditionns(-5°C—+56°C).
2 Scientific design and advanced processing technique
——SNOWKEY tube ice maker has scientific design and can also make the best ice making system according to customer's actual demand, with world leading ice making technology and processing and testing equipments. Each part is processed with strict technique requirement and strictly tested before using.
3 Sanitary
——Quality and sanitary tube ice maker is the aim of SNOWKEY. All parts contacting with water are made of stainless steel SUSSO4 or SUS316L and PE material. Tube ice produced is sanitary without smell, meeting HACCP and PDA certificate requirement.
4 Efficient and environment friendly
——With stable continuous running, SNOWKEY tube ice maker realizes the running without energy wasting. Compared with other ice making equipments, SNOWKEY tube ice maker boasts the advantages of compact structure, small area, low production cost, high refrigeratjon effect and low energy consumption, etc.





-Rifrigerant direct evaporation with high ice making efficiency;
-Sepacial water line design to guarantee ice quality(even thickness,beautiful tint,clean and sanitary) and water saving;
-Special refrigeration loop design to greatly improve refrigerantion effect and ice doffing efficiency;
-The only moving part is the durable ice cutting system to guayantee the running performance and lengthen the service life;
-Efficient heat conducing pipe to ensure meet the sanitary requirement of the wholse rifrigeration process and greatly improve the system rafrigeration efficiency
