Infrared Thermal Camera, 100*80 Resolution, Infrared Image Mode, -20 - +600 Degree Centigrade SL100

FOB Price

Negotiable / Piece

1 Piece(Min.Order)

Supply Ability 500 Piece / Pieces per Month
Port Shanghai
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Shanghai, China	Brand Name:	Sunlight	Model Number:	SL100(-20°C-+600°C)
Usage:	Industrial	Theory:	Infrared Thermometer	Accuracy:	±2°C
Temperature Range:	-20°C-+600°C

Product Description

Descriptions:

SL100 Series IR Thermal Imagers are designed with infrared detector 100*80 pixel as the core and supported with high-quality optical lens, ease-of-use operating system. It is precise to measure, clear to view on images, easy to carry with and offers a price you can totally afford. Choosing a SL100 means a significant work effectiveness and high temperature measurement accuracy, which is especially a perfect choice for users who are already used to point-contact thermometers.
Applicable industries:electric power,construction,electronics,smelting,energy,railway,automobile,petrochemical.

Specifications:

Model	SL100
Sensor Type	Uncooled Focal Plane Arrays
Resolution	100 * 80
View of View/Minimum Focus Distance	12°×9.4°/0.1m
Spatial Resolution (IFOV)	2.2mrad
Image Mode	Infrared
Focus	Manual
Infrared Spectral Band	8~14um
NETD	≤0.08°C@30°C
Temperature Range	-20°C~600°C
Accuracy	±2°C or ±2% (whichever is greater)
Features
Display Type	2.8"TFT LCD; Ratable
Palettes	Iron, Iron-Invert, Rainbow, Feather, Grey, Grey Inverted
Images Adjustable	Auto/Manual
Image Format	*·UIR
Video Output	Support: PAL(50Hz) or NTSC(60Hz) (socket selection required)
Measurement Mode	Movable Spot, Area(MAX,MIN)
Parameters Setting	Emissivity, Distance, Temperature, Relative Humidity
Self Temperature Calibration	Every 60 Seconds
High/Low Temperature Alarm	Yes
Laser Pointer	Yes
Image Capture	Yes
Image Storage	2GB SD Card
Temperature Units	°C/°F
Support Languages	English/Simplified Chinese
Factory Setting	Yes
Power Mode	Standard / Power Saving
Analyzing Software	Standard Version
Water Proof Rating	IP54
Impact/Vibration	25G/2G
General Characteristics
Power	Li-ion 1250mAh
Product Color	Red and Gray
Product Net Weight	500g
Product Size	170mm * 80mm * 160mm
Standard Accessories	Batteries, Seat Charger, SD Card (2G), Card Reader, Camera Cover, Software CD
Standard Individual Packaging	Gift box, Toolbox, User Manual
Standard Quantity Per Carton	5PCs
Standard Carton Measurement	545mm × 380mm × 325mm
Standard Carton Gross Weight	11.6 Kg
Optional Accessories*
Socket,Power Adapter,Video Cable,16G SD card,Vehicular Power Cord,Hood 38°wide-angle Lens,12°,6.4°,3.8° Telephoto Lens Temperature Rage(600°C,1000°C,1500°C)

Contrast:

Specifications
Model	SL80	SL100	SL160A
Sensor Type	Uncooled Focal Plane Arrays
Resolution	80 * 60	100 * 80	160*120
View of View / Minimum Focus Distance	10°*7.5°/0.1m	12°*9.4°/0.1m	20°*15°/0.1m
Spatial Resolution (IFOV)	2.2mrad
Image Mode	Infrared
Focus	Manual
Infrared Spectral Band	8~14um
NETD	≤0.08°C@30°C
Temperature Range	-20°C~300°C
Accuracy	±2°C or ±2% (whichever is greater)
Features
Display Type	2.8"TFT LCD; Ratable
Palettes	Iron, Iron-Invert, Rainbow, Feather, Grey, Grey Inverted
Images Adjustable	Auto/Manual
Image Format	*·UIR
Video Output	Support: PAL(50Hz) or NTSC(60Hz) (socket selection required)
Measurement Mode	Movable Spot, Area(MAX,MIN)
Parameters Setting	Emissivity, Distance, Temperature, Relative Humidity
Self Temperature Calibration	Every 60 Seconds
High/Low Temperature Alarm	Yes
Laser Pointer	Yes
Image Capture	Yes
Image Storage	2GB SD Card
Temperature Units	°C/°F
Support Languages	English/Simplified Chinese
Factory Setting	Yes
Power Mode	Standard / Power Saving
Analyzing Software	Standard Version
Water Proof Rating	IP54
Impact/Vibration	25G/2G
General Characteristics
Power	Li-ion 1250mAh
Product Color	Red and Gray
Product Net Weight	500g
Product Size	170mm X 80mm X 160mm
Standard Accessories	Batteries, Seat Charger, SD Card (2G), Card Reader, Camera Cover, Software CD
Standard Individual Packaging	Gift box, Toolbox, User Manual
Standard Quantity Per Carton	5PCs
Standard Carton Measurement	545mm × 380mm × 325mm
Standard Carton Gross Weight	11.6 Kg
Optional Accessories*
Socket,Power Adapter,Video Cable,16G SD card,Vehicular Power Cord,Hood 38°wide-angle Lens,12°,6.4°,3.8° Telephoto Lens Temperature Rage(600°C,1000°C,1500°C)
