Home > Products > CCD Box Camera > 1/3 sony super had ccd 480tvl color box camera with Auto-Iris
1/3 sony super had ccd 480tvl color box camera with Auto-Iris
USD $40 - $60
/ Piece
10 Pieces(Min.Order)
- 10000 Piece / Pieces per Month
- Shenzhen
- T/T L/C D/P D/A Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | Maxvi | |
| Model Number | ES500-MV-F62C/A |
Product Description
Specifications
1.11/3 sony super had ccd 480tvl color box camera;2.Auto-Iris controlled by DC;
3.Low Illumination;
4.CE,RoHs and FCC;
1/3 sony super had ccd 480tvl color box camera with Auto-Iris ;
Characrer:
1. 1/3 "sony super had
2.480TVL with auto-iris and audio;
3.Min. Illumination(F1.2, 30IRE)
4.High Performance Menus For Functions
5.RS-485 Communication Control
Specification:
| Specification: | ||||||||||
| Model | ES500-MV-F62C/A | |||||||||
| Signal System | NTSC | PAL | ||||||||
| Effective Pixels | 768(H)*494(V) | 752(H)*582(V) | ||||||||
| Image Sensor | 1/3 inch High sensitivity CCD | |||||||||
| Video Output | 1.0Vp-p Composite Signal(75 ohms) | |||||||||
| Sync.System | Internal Sync | |||||||||
| S/N Ratio | 52dB Min.(AGC off) | |||||||||
| Hori. Resolution | 480TVL | |||||||||
| Min. Illumination | 0.05LUX/0.0002 LUX(sense up auto) | |||||||||
| Brightness | 0~100 | |||||||||
| Shutter | AUTO/OFF/A.FLK/(X2~X512)/(1/90000~1/160) | |||||||||
| DSS | OFF/AUTO( X2~X128) | |||||||||
| 3D-NDR | ON/OFF(0~63) | |||||||||
| White Blance | ATW/PUSH/MANUAL | |||||||||
| AGC | OFF/LOW/MID/HIGH | |||||||||
| WDR | Up to 60dB(LOW/MIDDLE/HIGH) | |||||||||
| BLC | LOW/MID/HIGH | |||||||||
| ECLIPSE | ON/OFF(16 Zones) | |||||||||
| Stabilizer | ON/OFF | |||||||||
| Digital ZOOM | X1.00~X6.13 | |||||||||
| Day&Night | AUTO/DAY/NIGHT/EXT/IRED | |||||||||
| Night Burst | ON/OFF | |||||||||
| Motion Detection | ON/OFF(4 Programmable Zone) | |||||||||
| Privacy | ON/OFF(8 Programmable Zone) | |||||||||
| D-EFFECT | V-FLIP/MIRROR/ROTATE | |||||||||
| Sharpness | 1~100 | |||||||||
| Baud Rate | 4800/9600/19200/38400/57600 | |||||||||
| OSD Language | ENG/KOR/RSN/CHN/SPN/PRN | |||||||||
| Applicable Lens | DC iris/Manual Lens | |||||||||
| Supply Voltage | 12V DC(+10%~20%) | |||||||||
| Power Consumption | 2.4W(Max) | |||||||||
| Oper.Temp./Humidity | ‘-10°C~50°C(14°F~122°F)/30%~80% RH | |||||||||
| Stor. Temp./Humidity | ‘-20°C~60°C(-4°F~140°F)/20%~90% RH | |||||||||
