Mobile Steel Ramp / Steel Trailer Ramp

FOB Price

USD $4,500 - $5,000 / Set

1 Set(Min.Order)

Supply Ability 100 Set / Sets per Month
Port QINGDAO
Payment Terms:T/T Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Shandong, China	Brand Name:	Truewin	Model Number:	TWMD
Lift Mechanism:	Telescoping Lift	Lift Drive / Actuation:	Hydraulic	Power:	2.2KW
Rated Loading Capacity:	10T	Min. Lifting Height:	1.1M	Max. Lifting Height:	1.7M
Table Size:	2.1M*7M	Overall Dimensions:	2.1M*7M	Weight:	2300KG
Certification:	CE ISO9001	Warranty:	1 Year	After-sales Service Provided:	Overseas third-party support available

Product Description

DCQY Stell Yard Ramp

Product Description

All-steel welded construction
Capacities from 16,000 to 60,000 pounds
Wide range of capacities and sizes offered
Solid rubber tires standard, pneumatic tires optional
Steel serrated grating
Double-action hydraulic pump

Industrial yard ramps are simply moved into position at trailers, railcars, or docks. The operator utilizes a self-contained, double-acting hydraulic pump to adjust the unit to the proper position. In minutes you are ready to load or unload freight.

Solid 18" rubber tires provide easy positioning and towing. Open serrated steel grating provides excellent traction while preventing build-up of snow, water, and other debris. Beveled approach provides a smooth transition.

For truck or railcar to ground applications choose a 36' unit including a level-off. Choose a 30' straight design for quick loading from dock to ground.

Mobile Loading Dock Ramp Information
1> The regular mobile of this ramp is : width -2m length -11.2m,
2> Adjusting height range -0.8m-1.85m,
3> And it aslo can be designed and produced accordign to customers requirements .
4> This machine is suit for :often materail handling ,warehouse .wharf ,logistics center working place

Mobile Loading Dock Ramp (with landing gear) Dimension
1	Model Number:	DCQY -10
2	Rated Loading Capacity:	10 Ton
3	Working form:	With landing gear (manual one)
4	Max adjustable height:	1800mm
5	Overall length* Overall width:	11200*2100mm
	Platform Size:	2400*2100mm
	Slope Size:	7500*2100mm
6	Table Material:	Gear steel grating (Function:anti-skidding, avoid ponding)
7	Lifting plate:	Size:1000mm Plate Lip: 300*20mm
8	Landing gear	Quantity: 1 Pair Static Load: 40 TON
9	Solid tire	Size: 500-8B Diameter:450MM
10	Safety locking	Quantity: 2 pcs
10	Safety locking	Function: lock the container when loading and unloading

Foldable front lips(12mm steel plate) can meet the height changes of trucks.

Moves easily on two big pneumatic tires(solid tires available).

A manual 2-speed hand crank for easy one-person height adjustment.
(Optional hydraulic pump or hand crank for positioning yard ramp height).

Our products are widely used in terminals, stations, warehouses and other places. According to the different

needs of users, as the special design in terms of dimensions, load bearing and so on. Hydraulic loading ramps

mounted on the side of the dock, and the dock floor and sides flush
