450Kw Industrial Frequency Screw Air Compressor For Sale

Name: 450Kw Industrial Frequency Screw Air Compressor For Sale
Brand: ZIQI, ZIQI
SKU: 131568241
Availability: InStock

ZiQi Compressor (Shanghai) Co., Ltd.

US$ 11,000 - 250,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Screw

Configuration:

Other, Stationary, ISO9001

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Screw

Configuration Other, Stationary, ISO9001

Power Source AC Power

Lubrication Style Oil-less

Mute No

Place of Origin Shanghai, China

Brand Name ZIQI, ZIQI

Model Number GA-450A/W VFC

Voltage 380,3000 ,6000,10000/3/50,60

Dimension(L*W*H) 4650x2300x2400mm

Weight 9900KG

Certification ISO9001

Warranty One Year

After-sales Service Provided Overseas service center available

450Kw Industrial Frequency Screw Air Compressor For Sale

Product Description

Production Name		Screw air compressor
Model Number		GA-450A/W VFC
Brand Name		ZIQI
Configuration		Stationary
Air displacement/ exhaust pressure	mmm/min/MPA	8.30-83.0/0.7 8.10-81.0/0.8 7.10-71.0/1.0 6.00-60.0/1.3
Compressor series		single stage
Cooling method		A-air Cooling W-watering Cooling
Exhaust temperature	℃	Air Cooling <Ambient temperature +15℃ Watering Cooling<40℃
Water temperature	℃	≤32
Water pressure	MPa	0.2-0.6
Noise level	B(A)	86 2
Transmission		Flexbility direct drive
Electric suppy	V/ph/Hz	380,3000 ,6000,10000/3/50,60
Motor Power	KW	450
Lubricant oil	L	230
Starting method		Frequency start up
Dimension(LWH)	mmxmmxmm	4650x2300x2400mm
Weight	Kg	9900
Exit diameter	mm	150
Cooling water connector pipe diameter	mm	50

Advantages:

Using the renowned US Dynisco andapt to the high wearing and corrosion producing environment.
High quality oil and air separator core,the oil content though profession strict test<3ppm
Adopt ZIQI unique reverse-lock technology,oil never leak.Italy manuli,life will be five times longer compared to ordinary rubber tube
German Original twin-screw air end,triple-seal,patent pruducts,air end never leak oil.
The original allocation with high efficient steady intake valve,more fuelefficient,high reliability.
high quality,and low price.
various specification and models for your choice.
Lower noise
Good after-sales service
Superior and compact designing

Frequency inverter air compressor cost comparison

in the wholo cycle of compressor operation,energy saving will far exceed the compressor price

Technical Parameter

Detail Images
