FS-50 Optic Fusion Splicer

Specifications

1.
   Product Description

   The FS-50 series  Optic Fusion Splicer is a newly designed and very popular splicing machine. Its strong function and extremely low loss make it perfectly meet the fiber trunk line and FTTx application requirements. With the lightweight and compact body, it can easily work under narrow environments.



   Adopting the new and high-speed image processing system and digital design, its LCD screen could clearly display the fiber alignment and splicing process.

   Adopting the special precision- positioning technology, it could automatically and accurately splice fiber in 8 seconds.

   Adopting embedded real time operating system, it provides good operating interface and rich function.



   With built-in large capacity lithium battery, the FS-50 series Optic Fusion Splicer provides reliable security for long- time fieldwork.

   With built-in real time compensation system of temperature, humidity and air pressure,  the FS-50 series  Optic Fusion Splicer could automatically adjust with environment changes and ensure the low loss splicing even under adverse circumstances.



   Features

   1. Optic Fusion Splicer
   2. 8 seconds splicing time, 30 seconds heating time
   3. Smart size and lightweight, only 2.8kg including battery
   4. High-resolution true color 5.7” LCD screen
   5. Multi-language
   6. The advanced core to core fiber profile alignment system (PAS)
   7. Real time battery capacity monitoring
   8. 220 times splicing and heating with one fresh battery charge
   9. Up to 4000 times electrodes lifespan
   10. Max. wind velocity is 15m/s
   11. Enhanced wind and dust prevention ability via new wind cover deisgn
   12. 3 splicing modes: auto, half-auto and manual
   13. Built-in super high-brightness LED supply convenience for night work
   14. Auto splicing loss calculation
   15. 4000 test records storage
   16. USB data interface &VGA
   17. Automatically splicing with wind shield covered
   18. Automatically heating with heating covered

Specification

Standard Accessories

1)   Optic Fusion Splicer

2)   Cleaver

3)   Spare Electrodes

4)   Stripper

5)   Cooling Tray

6)   V groove Cleaning

7)   Blow Brush

8)   Alcohol Dispenser

9)   Monitor Coating

10) Monitor Cover

11) USB Flash Disk

12) AC Adapter/Battery Charger

13) Battery Charger Cable

14) Battery Pack

15) CD

16) Manual

17) Carrying Case

Ordering Information

FS-50-PA

1)  PA=Power Adapter

     PA1: USA power adapter

     PA2: EU power adapter

     PA 3: UK power adapter

  1. Standard warranty is 12 months.

  2. Extended warranty is available with reasonable additional cost.
