Sand core shooter

Specifications

Sand core shooter
PLC control
Adjustable technics parameters
Mold tempe

Company indroduction:

Qingdao Powerful Mechanical & Electrical Co., Ltd. is a large-scale enterprise specialized in the production of mechanical moulding line. The main products are: the production line of clay sand casting equipment ,V method casting equipment, sand reclamation equipment ,resin sand molding production line of glass sand reclamation equipment of mechanized moulding lines; series mixer; bucket elevator and climbing charge; series of environmental protection dust remover and so on..



Products  Detail:

Sand core shooter

1:sand core shooter die casting machine adopt special design, no big bottom-closing-force during sand shooting, no shock and big force to machine frame.

2: Quick and convenient sand cleaning system for shooting head, shooting

3: plate, sand shooting nozzel.

4: Quick hydraulic metal mould change system.

5: Advanced and powerful low-pressure sand shooting device.

6: Top and bottom core ejection system. Pre-press quick core stripping, small damage, no core-repairing

7: Outer-machine-core-picking, stable core ejection, convenient for core-picking.

8: Gas generator adopt magnetic pump, high guaging precision, long service life time.

Z946 sand core shooter technical parameter:

Type	Z946
Molding plate size(mm)	750*400
Cover die thick(mm)	150
Movable mould minimum thick(mm)250
Maximum sand core weight(kg)	20
Sand copper capacity(kg)	200
Control	Pneumatic/hydraulic
Electric heating power(KW)	30
Operation mode	manual/automatic

 Special design based on the requirements of client is available

Z946 sand core shooter picture:

Sand core shooter:
