headman china cnc automatic lathe machined part manufacturer

Specifications

1.Max swing diameter over bed :420mm
2:Max swing diameter over carriage :230mm
3.Max length of workpiece:750mm

Headman China CNC Automatic Lathe Machined Part Manufacturer



Features

• The flat bed has been quenched and grinded ,high rigidity
• Central lubrication is being used on ball screw and slide way,heat restoration is less ,accuracy is assured
• Electrical 4 position tool rest is position by precise chuck repeating accuracy is high
• Rapid cam clamping device is used on tailstock





Model	CKI-6140
Max swing diameter over bed          mm	420
Max swing diameter over carriage   mm	230
Max length of workpiece                  mm	750
Width of guide rail	340
Model of chuck	D6/Φ200
Spindle rotation speed	2800RPM
Variable structure of spindle box	Vari
Spindle motor	5.5kw
Spinlle head and spindle taper	D-6
Diameter of spindle hose               mm	Φ70
Max moving speed of X axies         m/min	6
Max moving speed of Z axies         m/min	8
Diameter of sleeve	Φ58
Travel of sleeve	120
Taper of tailstock sleeve	M4
Positioning accuracy                     mm	0.01
Dimension	2170*1200*1640
Net weight	1600





Standard accessories

1. Tai wan SYNTEC system

 2.4 position turrent

3.Three jaw chuck

4.Tool and tool box



Optional accessories





1.Fanuc 0i-mate system or chinese GSK or KND system

2,Six position turrent

3,Hydraulic tailstock

4,Hydraulic chuck(taiwan or chinese)





After-sales Service:



Warranty is a year. Parts are free of charge to be offered during this period. Oversea service need to charged extra in and out of warranty





Our production workshop

        Our company independent planning and construction of modern vertical machine center production line ,CNC milling machine production line ,Dragon frame CNC machine production line , electric discharge machine production line, milling machine production line, grinder machine production line, precise head assembly workshop etc.







Our development team

       We have a group of development team that they have professional theory profound skills, technical specialization, rich experience in the industry of the first-class technical research











Our certificate of honor

• There are 8 Intellectual property rights,5 the patent
• In 2008, Our own brand”JOINT” has been the top quality machine’s signal in domestic sales JOINT also has been recognized as”Guangdong Famous Brand”
•  In 2008, Milling machine was recognized as” TOP 10 Famous Brand of Milling Machine “ in China
• ,In 2011,our company has been recognized as” national grade HI-Tech Enterprise”.
• The company set up a ISO9001:2000 quality guarantee system
• our product through “the country machine quality supervision and inspection center “certification testing
