DIN1837 HSS Metal Slitting Saw Blades
USD $1 - $80
/ Piece
100 Pieces(Min.Order)
- 100000 Piece / Pieces per Month
- Shanghai/Ningbo
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Jiangsu, China | Brand Name | TONGYU | |
| Model Number | TY10-19.1.2.1 | Material | Other, High Speed Steel, High Speed Steel | |
| Diameter | 25mm-315mm | Type | Other, circular mill, Fine teeth/ corse teeth | |
| Coating | TiN |
Product Description
Specifications
1.Guaranteed hss raw material2.With comparative price advantage
3.Customization is available
HSS Metal Slitting Saw Blades
Specification:
| 1. Standard: | DIN1837 Fine teeth( corse teeth is also available if you are in demand) |
| 2. Material: | HSS 4341(W4Mo3Cr4V), 6542(W6Mo5Cr4V2) |
| M35 (W6Mo5Cr4V2Co5), M42 (W6Mo5Cr4V2Co8) | |
| 3. Hardness: | HSS4341:HRC63-64, HSS 6542:64-65, HSS M35:HRC 66-67 HSS M42:HRC 67-68 |
4. Surface finishing: | Bright finishing;Tin-coated; TiAlN; or customization |
| 5.Application: | Cutting or milling narrow and deep grooves on hard materials, structural steel, grey cast iron and medium hard nonferrous metals. Cutting by correctly chosen HSS slitting saw blades allows to obtain very high accuracy of cutting or grooving parts. |
6. Size
| Thickness | |||||||||||||||||
| D | d | 0.3 | 0.4 | 0.5 | 0.6 | 0.7 | 1 | 1.2 | 1.5 | 1.6 | 2 | 2.5 | 3 | 3.5 | 4 | 5 | 6 |
| mm | mm | Number of teeth | |||||||||||||||
| 32 | 8 | 80 | 80 | 80 | 64 | 64 | 64 | 48 | 48 | 48 | 48 | 40 | 40 | 40 | 40 | 32 | 32 |
| 40 | 10 | 100 | 100 | 80 | 80 | 80 | 64 | 64 | 64 | 64 | 48 | 48 | 48 | 40 | 40 | 40 | 40 |
| 63 | 16 | 128 | 128 | 128 | 100 | 100 | 100 | 80 | 80 | 80 | 80 | 64 | 64 | 64 | 64 | 48 | 48 |
| 80 | 22 | 160 | 160 | 128 | 128 | 128 | 100 | 100 | 100 | 100 | 80 | 80 | 80 | 80 | 64 | 64 | 64 |
| 100 | 22 | 160 | 160 | 128 | 128 | 128 | 128 | 100 | 100 | 100 | 80 | 80 | 80 | 80 | 64 | ||
| 125 | 22 | 160 | 160 | 160 | 160 | 128 | 128 | 128 | 100 | 100 | 100 | 100 | 80 | 80 | |||
| 150 | 32 | 160 | 160 | 160 | 160 | 128 | 128 | 128 | 128 | 100 | 80 | 80 | |||||
| 160 | 32 | 160 | 160 | 160 | 160 | 128 | 128 | 128 | 128 | 100 | 100 | 100 | |||||
| 200 | 32 | 200 | 200 | 200 | 160 | 160 | 160 | 128 | 128 | 128 | 128 | 100 | |||||
| 250 | 32 | 200 | 200 | 200 | 160 | 160 | 160 | 160 | 128 | 128 | |||||||
| 315 | 40 | 200 | 200 | 200 | 200 | 160 | 160 | 160 | |||||||||
Other sizes are also available according to your requirement. (OEM)
Material: the quality of HSS tools are basically decided by HSS raw material and heat treatment.
We can keep a strict control of these procedure.
Package: one piece packed in one paper box. Then in exporting outer carton, then in pallet.
Pls. contact us freely for more information, I will reply you ASAP!
Hope you will enjoy a comfortable cooperation with us!
