Dental autoclave MAU-E18

Specifications

1.Low noise

2.Cristal LCD display

3.PHILIPS chip

Product Parameters

Model      Voltage/Power     Chamber Size   Outside Size    Packing Size      Net Weight

MAU-ZOE18   220V/1500W   φ245×360mm   560×470×400mm   655×560×495mm  47kg

MAU-ZOE23   220V/1700W    φ245×470mm   675×470×400mm  765×560×495mm  53kg

Main Features

Sterilization Class : CLASS B

Sterilization Temperature : 121°C,134°C

Special Program : HIV, HBV long-sterilization program

Dry System : Vacuum drying system

Display : High-light LCD display

Testing System : Bowie&Dick Test

                                Vacuum Test

                                Helix Test

Control Precision :  Temperature: 1°C

                                    Pressure: 0.1bar

Sterilization Data : Build-in mini printer

Safety System :  Relief valve

                              Hand lock door

                              Pressure lock system

                              Pressure and temperature overload protection

                              Alarm system

Tray Holder : 5 layers tray holder with 3 trays

Chamber : Medical stainless steel 304

                    Max working pressure:2.3bar

                    Min working pressure: -0.9bar

                    Max temperature: 145°C

Operation Temperature : 5~40°C

Noise : <50db

Water consumption in one cycle : 0.16L~0.18L

Functions

1.It fit EN13060 standard with opening tank on the top which is convenient to cleaning.

2.Standard Class B with three times vacuum and drying, the remaining temperature of sterilized instrument is less than 0.2%.

3.The vacuum data can reach -0.8bar, it fits various instrument, including package,unpackaged,solid,hollow,multi-apertures and inset pipes. It makes sure the instrument can   be sterilized completely.

4.Fuzzily computer controlled, digital bright show. The interface is modularized panel for easy operation.

5.It is installed with BOWIE&DICK which measures the penetration of water steam.

6.It has vacuum text which can make sure the ability of texting vacuuming.

7.Sterilization cycle self-comment.

8.Fast and independent steam generator.

9.Large capacity instrument tray made of SS. SU304.

10.Safety lock and triple temperature.overload protecting

11.Auto/Manual water adding

12.Inset cleaning device

13.Special function of creating medicine cotton and sterilizing rubber items

14.Handsome aspect and good quality

15.Cristal LCD display

16.4-Button panel with the LCD display, so convenient.

17.Built-in mini printer which can record the sterilizer information.

18.Warning message, Error is made easier to judge.

Advantage

1.High density air filter,eliminating impurity in air,ensuring the returned air dry and pure.

2.Efficient double-head vacuum pump,low noise,vacuum ability could get -0.92Bar,double head ensure the balance during working and stable vacuum state in the chamber.

3.Electronic data output,the sterilization information can be saved into memory disk as a txt file,in connection with computer to analysis,realizing digital sterilization.

4.The multiplex tray holder of sterilizer is single stretching molding,painting and polishing treatment,with good compression bear and suit various load.It could set 5 trays on   the holder simultaneously when revolve it 90°.

5.Circular heating little difference in temperature.

  Pressure-prevention and corruption-resistance makes it highly reliable.

  Alloy heating loop protects against damage by no-water heating.

  Spcious cavity makes it easy to clean.

6.Original fuzzy control system driven by steam generator adoptsPWM(pulse with modulation),able

  to discriminate the fine differences in temperature allowances and to adjust the modulated waves

  correspondingly thus making temperature rise at the same speed each time.

7.Chamber is made of purple glass surface copperplate,

  plastically metamorphosed by the extrusion under 500-ton oil pressure.

8.Stable ULKA water pump made in Italy.

9.PHILIPS chip, famous world, powerful memory, process data fast and reliable.

10.MAXIM is the worldwide leader of analog, mixed-signal, also head of high frequency and digital circuit research, development, manufacture, smooth circuit controlling.

11.MOTOROLA precise-level pressure sensor, single crystal silicon thin film semiconductor strain gauge, can accurately sense the pressure within the sterilizer.

12.ST semiconductor, proud of high efficiency silicon, make the control more accurate and rapid.

13.ATMEL Corporation, the world's advanced semiconductor design, manufacturing and marketing leader. ATMEL microprocessor, safe, reliable and feature-rich.

14.OMRON electromechanical conversion structure, powerful loading capacity, 10 life-time.

15.SD Japan expert of temperature sensor, swift measurement, ready to deliver in time the temperature inside the sterilizer, superior.
