leading supplier of paper wrapped wire

FOB Price

USD $9.15 - $9.35 / Kilogram

400 Kilograms(Min.Order)

Supply Ability 500 Ton / Tons per Month
Port Shanghai Tianjin Qingdao
Payment Terms:T/T D/P D/A Credit Card

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price

Product Details

Place of Origin:	Henan, China	Brand Name:	HUAYUAN	Model Number:	ZB-HY-D
Type:	Insulated	Application:	Other, Oil-immersed Transformer Reactor Generator	Conductor Material:	Copper
Conductor Type:	Solid	Insulation Material:	Other, telephone cable paper, NOMEX,3M paper

Product Description

Specifications

paper wrapped wire
Specification; a 0.8-5.0mm;b 2.0-16mm
Standard: IEC GB NEMA
Feature: uniform wrapping

leading supplier of paper wrapped wire

Size of paper wrapped wire

a 0.8—5.0mm

b 2.0—16mm

Thermal class of paper wrapped wire

90/105/ 120 /130 /180/ 220

insulation materials of paper wrapped wire

Brief description of paper wrapped wire

Standards	IEC GB NEMA
Insulation Thickness	0.27mm, 0.33mm, 0.45mm or according the customer requirement
Characteristics	Uniform ,Fastness wrapping, tightness, uniformity, without drape

Manufacturing process of paper wrapped wire

Applications of paper wrapped wire

Reactor. Motor

Oil-immersed Transformer

Generator and other electric devices

Packing

inner packing: different wooden spool according to wire guage

Out packing: wooden cases or according the requirement of customer

Test equipment ensure paper wrapped wire that are qualified

Test report of paper wrapped wire

Name		paper wrapped wire
Diameter		3.6mm*8.5mm
Standard		GB/T7673.3-2008
Test Item		Unit	Technical Requirement	Test Result
Appearance			Uniform, no missing layer, no wrinkling and cracking	Ok
Bare Conductor	a	mm	±0.05	3.605
	b	mm	±0.07	8.495
Thickness of insulation film		mm	0.405----0.45 ----0.50	0.48
springback angle		°	The springback Angle of conductors less than 5°	4.6
Resistivity (20°C)		Ω.mm²/m	≤0.017241	0.017160
Elongation		%	a:nominaldiameter(mm) ≤2.5 30% >2.5 32%	45%
Wrapped overlapped		mm	≥2	2.3
package			Meet the export standards	Ok
Quality Control Result			Ok

Application

11. Best service

1) .Trail order is welcomed, you can test our quality before making large quantity, even though we are wholesales supplier

2). We issued test reports for every shipment.

3). You can enjoy discounting and priority to produce first after you become to be our regular client.

12. Company Advantage

1). About 20 years manufacture experiences.

2). Flat wire Audit by UL Company and BV Company

3). We have a big Quality Control Team and can guarantee the quality and time of delivery

4). Many trade companies place orders from us.
