Qingfeng Cashmere Carding Combination Machine

Specifications

Application:
Suited materials: cashmere, camel wool, yak wool.etc.
In the process of this machine, the raw stock will be

Cashmere Carding Combination Machine including the following machines :

1. Feeding Bucket Type FB006

Application:

This bucket is designed as the first process of the blowing lay-down. The raw stock reserved in the bucket will be plucked in an appropriate potion by spikes on the lattice and then evenly fed into next process.

Main features:

Raw stock horizontally fed and vertically plucked enables its blending, opening and impurities removing;

Inverter control of lattice speed according to productivity

Opening roller ensures a homogeneous feeding

Main Specification

Working width:  960mm

Installed power: 1.5Kw

Overall dimension: ( L × W × H )  2215×1040×2500 ( mm )

2.  Opener Type FB101

Application

This machine is designed to pre-open raw stock. Under the interaction of proper card clothing and speed, materials of a large mass twisted together will be carded into small bundle.

Main features

Equipped with a coarse clothing;

Four groups of worker rollers and transfer rollers equipped to cylinder

Slow speed of rollers.

Main Specification

Working width: 1020mm

Installed power:  shared motor with opener FB102 an parallel card FB111 (2.8Kw)

Overall dimension: ( L × W × H )  1536×1837×1570  ( mm )

 3.Opener Type FB102

Application

It is mainly used to fine open the fibers from the opener FB101.

Main Feature

A relative less coarse clothing than FB101

Three groups of worker rollers and transfer rollers equipped to cylinder

Faster roller speed than that of FB101

Main Specification

Working width: 1020mm

Installed power:   one main motor with FB101 opener and FB111 parallel card (2.8Kw)

Overall dimension: ( L × W × H )    1018×1837×1420 ( mm )

4.Parallel Card Type FB111

Application

 It’s mainly used to slowly open materials and removes shags and impurities embedded and form a smooth fiber.

Main Features

Four groups of shag removing rollers, condensing rollers and transferring rollers with different speed;

Equipped with special card clothing.

Main Specification

Working width:  1020mm

Installed power:  3.17KW

Overall dimension: ( L × W × H ) 2953×1837×1100 ( mm )

5.Semi-worsted Card Type FB200B

Application

This machine is able to carding natural fibers like cashmere, camel’s wool and yak’s wool. These fibers , as opened and fed into this machine, will be fed into cards manually or by chute feeder. Shags and impurities will be removed in this process and a fine product will be yielded.

Main specifications

Fiber length:  20-65mm

Production capacity:  3-5kg/h

Working width:  1020mm

Dimension:  (LXWXH) 3830×1770×1910mm

Net weight :  4T

Installed power:  3.97kw

6.High Efficiency Controlling Cabinets Type JNR

Product Feature

Centralized control of whole production line: Mitsubishi 10.4’ Colour HMI to adjust speed of each machine and to input, edit parameters and monitor the whole working

Communication Control:  Automatic control of PLC, HMI and inverters by the way fo communication; stepless speed adjustment of whole production line by imported PLC and 11 inverters.

Self-diagnosis of system: Clear fault display and textual illustration on HMI; High anti-interference ability; low fault rate; convenient operation , installation and maintenance.

System control of whole production line or individual equipment.

Equipped with speed sensor to clearly display each roller’s speed and prevent calendering.

Installed power /per line: 23 KW
