Pulse TIG AC/DC welding machine (Digital TIG200 Digital TIG210)
Most advanced technology:
3 optional wave pattern when welding aluminum,
1. Sin: The standard setting for a low noise and stable arc;
2. REc: With decreased edge steepness, for reducing noise levels compared to those that occur with the 100% rectangular waveform.
3. OFF: Stable but loud arc.
Easy Operation:
1. One Knob: Easily use the main one knob to adjust all parameters quickly and preciously.
2. Memory function: Pre-deposit 9 welding task to save time and keep highest quality of constant welding
3. Anybody who knows well about welding skills or never used
Fearture:
1. Compact volume
2. Light weight
3. Portable
4. Reliable and durable
5. Rigid structure suitable in any environment
Application:
Can be widely used in welding of unalloyed and non-alloy steels, stainless steels, nonferrous metals, aluminum and aluminum alloys
Model | AC/DC TIG 170 | AC/DC TIG 200 | AC/DC TIG 210 | AC/DC TIG 170P | AC/DC 200P | AC/DC 210P |
| ||||||
Single phase input 50/60 Hz | 170 | 200 | 210 | 170P | 200P | 210P |
Installedpower | 230 | 230 | 230 | 230 | 230 | 230 |
Fuse(delayed action) | 16 | 20 | 22 | 16 | 16 | 16 |
Power factor max | 0.8 | 0.8 | 0.8 | 0.95 | 0.95 | 0.95 |
Open circuit voltage | 62 | 62 | 62 | 62 | 62 | 62 |
Current range | 5-170 | 5-200 | 5-210 | 5-170 | 5-200 | 5-210 |
Duty cycle at (40°C) X% | 170 (35%) | 200 (35%) | 210 (35%) | 170 (35%) | 200 (35%) | 210 (20%) |
Dimensions | 44×21×43 | 44×21×43 | 44×21×43 | 44×21×43 | 44×21×43 | 44×21×43 |
Weight | 16 | 17 | 17 | 17 | 18 | 18 |
Why not try one sample first?Choosing our products,give yourself maximum profit. Inquires are typically answered within 24 hours !
Our salesmen will reply your inquiry within 24 hours. Any order is welcome. If you like to be our agent in your country, we can give you any support on the technique & other aspects.
If you have any questions ,please contact with us...
