'PBS-GQ19 self-reset Push Button Switch
- 1000000 Piece / Pieces per Month
- Ningbo or Shanghai
- T/T
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | WANSHFA | |
| Model Number | PBS-GQ19 | Protection Level | IP65 | |
| Max. Current | 2A | Max. Voltage | 36VDC |
Product Description
Specifications
1.PBS-GQ19 self-reset Push Button Switch2.OEM,ODM
3.15 years experience
4.good quality
5.CE,CQC
PBS-GQ19 self-reset Push Button Switch/push button switch
15 years' experience of manufacturing in push button switch
Specification:
| Rating | 2A 36VDC |
| Contact resistance | ≤50mΩ |
| Insulation resistance | ≥100mΩ |
| Withstand voltage | 500VAC |
| Switching life | ≥10000cycles |
Temperature-25~ +70°C
Relative Humidity( 40°C) ≤ 95%
Push Button Switch External AppearanceVisual measurement: surface of metals cleanness, no rust stain, no cladding shell off
Temperature-25~ +70°C
Relative Humidity( 40°C) ≤ 95%
Normal Load 3A AC 250V
Withstand VoltageAC250V (50Hz)/1min
Contact Resistance ≤0.05Ω
Insulation Resistance ≥100MΩ
Travel 4mm
Service Life 100,000 Cycles
Operating Force 4N
Center Distance2.2mm
Diameter7mm
Height21.4mm
Length of Terminal 5.1mm
Width of Terminal 0.5mm
Quantity of Terminals 2
Setup ModeVertical Plug-in
Color of KeyRed
Lock Mechanism Lockless
UsesInstrument,Meter,Household Appliances,
Weighing apparatus etc
Note:
1.All parts made of withstand high temperature and RoHS parts raw materials.
2.Please contact us to get the drawing of the switch. PBS-105 red power low voltage push button switch
