Home > Products > Directional Coupler > 698-2700MHz, IBS RF Directional Coupler(Silvery White)
698-2700MHz, IBS RF Directional Coupler(Silvery White)
- 500 Piece / Pieces per Month
- Shanghai/Shenzhen
- T/T
You May Like
-
670-2700MHz, IBS RF Directional Coupler
-
350-800MHz, RF IBS/BTS Directional Coupler (Cavity Coupler)
-
350-1000MHz, Low Frequency Outdoor Directional Coupler (Cavity Coupler)
-
400-450MHz, Low Frequency RF Directional Coupler (Micro-strip type)
-
800-2500MHz Micro-strip RF Directional Coupler with External Load
-
N-Connector RF Directional Coupler(698/700-2700MHz)
Product Details
Place of Origin | Anhui, China | Brand Name | SETSAIL | |
Model Number | YF-DC-0727-X-WF |
Directional Coupler Standard Export Cartons (450mm*350mm*340mm).
Product Description
Specifications
1. We are Manufacturer of RF Hybrid Coupler2. OEM Service is available
3. 300pcs in stock
4. Hybrid Coupler Best Price
Applications:
698-2700MHz, 5/6/7/8/9/10/15/20/30/40/50dB, Silvery, 200W, RF Cavity Directional Coupler
Used in IBS and BTS projects
1. Mobile Communication Network Optimization and In-door distribution system.
2. Cluster communication, satellite communication, shortwave communication and hopping radio.
3. Radar, electronic navigation and electronic confrontation.
4. Aerospace equipment systems.
Directional Coupler: 800-2500MHz
Technical Specifications:
Model Number | YF-DC-0727-06-WF | YF-DC-0727-10-WF | YF-DC-0727-15-WF | YF-DC-0727-20-WF | YF-DC-0727-30-WF |
Frequency | 698-2700 | 698-2700 | 698-2700 | 698-2700 | 698-2700 |
Insertion Loss | 1.7 | 0.8 | 0.5 | 0.4 | 0.3 |
VSWR | 1.25:1 | 1.25:1 | 1.25:1 | 1.25:1 | 1.25:1 |
Directivity | 20 | 20 | 20 | 20 | 20 |
Power | 200 | 200 | 200 | 200 | 200 |
Impedance | 50 | 50 | 50 | 50 | 50 |
Coupling | 0.8 | 1.0 | 1.0 | 1.2 | 1.5 |
RF Connector | N-female | N-female | N-female | N-female | N-female |
Relative Humidity | 5%-95% | 5%-95% | 5%-95% | 5%-95% | 5%-95% |
Color | Silvery | Silvery | Silvery | Silvery | Silvery |
Temperature | -35~+125 | -35~+125 | -35~+125 | -35~+125 | -35~+125 |
Weight | 0.23 | 0.23 | 0.23 | 0.23 | 0.23 |
Apllication | Indoor or Outdoor | Indoor or Outdoor | Indoor or Outdoor | Indoor or Outdoor | Indoor or Outdoor |
Note: Specifications can be changed according with customers' requirements.
