RF Microwave 800-2500/800-2700/700-2700MHz Micro-strip Power Splitter/Divider
- 20000 Piece / Pieces per Month
- Shanghai
- T/T Credit Card
- 2-way Multiband Power Splitter with wall mounting bracket, 200W, N-female
- 698-2700MHz 2-way Multiband Power Splitter with wall mounting bracket, 200W, N-female
- 800-2500MHz 2-way Multiband Power Divider with wall mounting bracket, 200W, N-female
- 800-2500MHz 2 way Multiband Reactive Power Divider with wall mounting bracket, 200W, N-female
- 800-2500MHz 2 way RF Power Combiner with wall mounting bracket, 200W, N-female
- 800-2700MHz 3 way RF Power Combiner with wall mounting bracket, 200W, N-female
Product Details
Place of Origin: | Anhui, China | Brand Name: | SETSAIL | Model Number: | YFTX-MPS-0825-04NF |
Packaging Details
Standard Exporting Cartons for Micro-strip power splitter
Product Description
Specifications
Micro-strip Power Splitter/divider2-way, 3way, 4-way microstrip power splitter
Low VSWR microstrip power splitter
ZTE supp
Technical Specifications:
800-2500/800-2700/700-2700MHz Micro-strip Power Splitter
Model | YFTX-MPS-0825-02NF | YFTX-MPS-0825-03NF | YFTX-MPS-0825-04NF |
Frequency(MHz) | 800-2500MHz/800-2700MHz/698-2700MHz /350-520MHz /350-1000MHz | ||
Insertion Loss(dB) | <=3.4 | <=5.5 | <=6.5 |
Isolation(dB) | >=20 | ||
VSWR | <=1.30:1 | ||
Power Capacity(W) | 50 | ||
Impedance(ohm) | 50 | ||
RF Connector | N-female | ||
Application | Indoor | ||
Operating Temperature(deg) | -35~+60 | ||
Color | Black-plated | ||
Relative Humidity | 5%-95% |
