China Rotogravure Printing Machine

Specifications

rotogravure printing machine 7 frequency motor snychronors 4 segment tension.

Machine Name: ASY-600/2600 Series China Rotogravure Printing Machine

Performance:

This machine is suitable for printing roll plastic film, non-woven cloth, thin leather, paper, aluminum foil, cloth and various soft packages with excellent performance and it is a kind of ideal printing equipment for wine box, shoe bag, milk film and vest bag.

Features

1. The latest improved gear box, 360°non-stopping registration device.

2. Movable type doctor blade, transverse reciprocating motion.

3. Far-infrared heating tube drying system.

4. Unwinding and traction adopts magnetic powder brake to make material moving more stable.

5. Rewinding and out feeding adopt magnetic powder clutch.

6. Current output type temperature control system makes heating quicker and electricity saving.

7. Turnover double-station unwinding and rewinding mechanism, receiving and replacing material without stopping the machine.

8. Obverse and reverse side once-through continuous printing.

9. side and up double drying oven,optional big printing cylinder device can extend the repeating length to 1200mm.(printing length)

10.Main Motor:electromagnetic speed regulation motor.



Main Technical Parameter:

Type	ASY-600	ASY-800	ASY-1000
Effective Printing Width	600mm	800mm	1000mm
Max.Width of Web	620mm	820mm	1020mm
Max.Printing Speed	70m/min	70m/min	70m/min
Max.Mechanical Speed	90 m/min	90 m/min	90 m/min
Max.Diameter of Unwind/Rewind	600mm	600mm	600mm
Inside Diameter of Roll Core	76mm	76mm	76mm
Diameter of Printing Cylinder	70~270mm	70~270mm	70~270mm
Accuracy of Registration	±0.2mm	±0.2mm	±0.2mm
Tension Control Range	3~25kg/Full Width	3~25kg/Full Width	3~25kg/Full Width
Heating Power of Oven	28.2Kw	36Kw	43.2Kw
Total Power	31Kw	43.5Kw	54Kw
Weight of Machine	6500kg	7000kg	7500kg
Overall Dimension	L8500×W2000×H2200mm	L8500×W2200×H2200mm	L8500×W2400×H22
