CYMB movable prefabricated houses

Specifications

Quick info of movable prefabricated houses:
1. Easy locate and relocate
2. Easy transport
3.Cost-Effective

Product Name:     CYMB  movable prefabricated houses

1.Company Profile:



Changshu Yahgee Modular Building Co., Ltd., (CYMB) a wholly owned subsidiary company of Yahgee Group, established in 2011. It covers an area of 166,500 square meters including 43,800 square meters steel structure production lines and 32,000 square meters interior decoration production lines.

CYMB specializes in the research, manufacture and sales of flat packed container house, container house, light gauge steel structure building, special container and other modular buildings.





Geographic Locations:





Our company located in Changshu, Jiangsu, close to Changshu Port and Shanghai Port.

To Shanghai port: 1 hour's drive.

To Changshu port: 30-minutes drive.

To Taicang port: 45-minutes drive.







2.  Container house for sale Product Info:

• Based on steel structure and light wall panels, composed of top structure, base structure, corner posts and 14 interchangeable wall panels.
• Match ISO dimensions, 4 individual houses packed together for Combined transportation. 75% transportation cost can be saved.
• Can Stack 3 storeys without any external support.

   Single Installation:



• Recommend standard external dimension: 6058(20’, L) ×2438(8’, W) ×2800(H)mm.
• For some special projects, 3000mm W, 9125mm(30’) or 12192(40’) L will be available.

Integral Installation:





Every individuar units It can be used individually, or combined them together horizontally or vertically (≤3-storey) to meet the using function in different areas.

1. We can offer you a full finished house which you can finish your location by a  crane, A building with 2-storey building can be finished in one day.

2. In order to save the transport cost we packed 4-6units in a bundle, a installation must be done to evey unit when they reached the local place. However, there is nothing to worry about, we will give you a installation vedio. After all the singel units finished we can do the lifting and combination.



3. Typcal Modular Unit-Accommodation:





This Vip room is combined by two flat packed container house with toilet and shower, the inner decoration, furnitures and electric appliances according to your requirement.

This Single and double room are both completed with toilet, the inner decoration, furnitures and electric appliances according to your requirement.







This one person room is completed with toilet and shower, the inner decoration, furnitures and electric appliances according to your requirement.

This two person room can be completed with toilet or not, the inner decoration, furnitures and electric appliances according to your requirement.

This four person room is without washroom, the inner decoration, furnitures and electric appliances according to your requirement.







4. Typcal Modular Unit: Office









We have variety options for office.

1. Use it individually

2. Two or more single units joint together to get more working space, also you can set some functional zones, such as meeting room, restroom, entertainment room, reception room.

3. Inner decoration, furnitures and electric appliances according to your requirement.





5. Typcal Modular Unit: Toilet/Barthroom





Public washroom, shower room, bathroom, kitchen room, laundry room and so on are available. Specific requirements,you are welcome to contact us.





6. Other Infomation for you:



Material





It is based  on steel structure and light wall pannels. There are some kind of wall pannel can be chosed EPS Steel Sandwich pannel, Pre-painted Steel Glass Wool Pannel, Pre-painted Steel Rock Wool, inner Partical board pannel.





Door and Window





    We can offer you different kind of door and windows, such as Sliding window, inward tilt-turn window, vertical sliding window.







Accessories





    We can offer you Stairs, Corridor, Toilet, Bath room and other accessories, according to your requirements.





7. Performance Parameters:



Performance		Particle board interior panel	Pre-painted steel interior panel	Reinforced type
Inner dimension (mm)		5856(L)* 2236(W)* 2505(H)	5876(L)*2256(W)*2505(H)	5856(L) * 2236(W)* 2505(H)
Floor live load (KN/m²)		2.0	1.5	2.0
Roof live load (KN / m²)		1.0	0.75	1.4
Wind resistance (KN / m²)		0.66	0.38	0.94
Thermal resistance	floor	R13	/	R21
	roof	R13	R13	R21
	Wall	R9	R9	R15
Stacking storey		≤3 storey	≤3 storey	≤3 storey
Seismic performance		8 degree	8 degree	8 degree
